| Brand | X-SECURITY |
| Maximum Resolution | 4 Megapixel (2688x1520) |
| Image Sensor | 1/2.9” Progressive CMOS |
| Lens | Motorized 2.7~13.5mm (H: 97°-28°; V: 52°-16°; D: 117°-32°) |
| Main Stream Rate | 2688x1520@(1–20 fps) / 2560×1440@(1-25/30 fps) |
| Extra Stream Rate | 704 × 576@(1–25 fps) / 704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| DORI | 64-210 (D), 25.6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Minimum Illumination | 0.006 lux@F1.0 (Color, 30 IRE) 0.0006 lux@F1.0 (B/W, 30 IRE) 0 lux (Illuminator on) |
| Dual Light | Operating modes: Intelligent Mode (Default, IR activated and switches to white LED when a target is detected) IR Mode White LED Mode |
| IR Range | 60 m (IR) 60 m (White light) |
| Image Enhancements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| SMD Plus | Yes (Motion detection based on human and vehicle) |
| IVS (Perimeter Protection) | Intrusion, line crossing (both functions support accurate classification and detection of vehicles and people) |
| Smart Search | Using microSD card or X-Security NVR |
| Network Interface | Ethernet 10/100M BaseT |
| Audio | Built-in microphone / 1 Input / 1 Output |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarms | 1 Input / 1 Relay |
| Remote Access | WEB interface, CMS (Smart PSS Lite / DSS / DMSS), Smartphone and NVR |
| Material | Metal |
| Interoperability | ONVIF (Profile S/Profile T); CGI |
| Power | DC 12 V / 3W, PoE IEEE802.3af |
| Operating Temperature | -40º C ~ +60º C |
| Protection Rating | Waterproof IP67 |
| Dimensions | 238.5 (L) x 90.7 (W) x 90.7(H) mm |
| Weight | 760 g |
