| Brand | X-SECURITY |
| Maximum Resolution | 4 Megapixel (2688x1520) |
| Color | Black |
| Image Sensor | 1/2.9” Progressive CMOS |
| Main Stream Rate | 2688 × 1520@ (1–20 fps)/2560 × 1440@(1–25/30 fps) |
| Extra Stream Rate | 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps) |
| Compression | H.264H; H.265; H.264; H.264B; MJPEG (only compatible with substream) |
| Lens | 2.8 mm (H: 95°; V: 52°; D: 114°) |
| Minimum Illumination | 0.008 lux@F1.6 (color, 30 IRE) 0.0008 lux@F1.6 (black and white, 30 IRE) 0 lux (IR on) |
| Image Enhancements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter Protection) | Intrusion, line crossing (both functions support accurate vehicle and person classification and detection) |
| Smart Search | Work together with Smart NVR to refine smart search, event extraction, and event video merging |
| Storage | MicroSD Slot up to 256 GB |
| Network Interface | Ethernet 10/100 BaseT |
| Audio | Built-in Microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Remote Access | WEB Interface, CMS (DSS/PSS), Smartphone, and NVR |
| Material | Inner Core: Metal Cover: Metal Decoration Ring: Plastic |
| Interoperability | ONVIF (Profile S/Profile T); .CGI; P2P; Hik-Connect |
| Power | DC 12 V / 3.3W, PoE IEEE802.3af |
| Operating Temperature | -30º C ~ +60º C |
| Protection Grade | Waterproof IP67 |
| Dimensions | 99.1 mm (D) x 121.9 mm (Ø) |
| Weight | 480 g |
