The DS-7216HGHI-M1(F) is a versatile 5-in-1 DVR designed for comprehensive video surveillance solutions. It supports up to 16 channels of video input using various formats including HDTVI, HDCVI, AHD, and CVBS, making it ideal for both new installations and upgrades of existing systems. This device is particularly well-suited for small to medium-sized businesses and residential applications, providing high-definition recording capabilities and advanced features such as motion detection and remote access.
| Brand | HIKVISION |
| Series | Value |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 16 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | 2 additional IP CH: Up to 18 IP channels (5 MP), replacing all BNC channels |
| Video Outputs | 1 Full HD HDMI and 1 VGA, simultaneous; |
| Display Resolution | HDMI: 1920x1080, 1280x1024, 1280x720, 1024x768 / 60 Hz VGA: 1920x1080, 1280x1024, 1280x720, 1024x768 / 60 Hz |
| Audio Inputs | Audio over coaxial 1 RCA Channel |
| Audio Outputs | 1 RCA Channel |
| Two-way Audio | Reusing audio input |
| Audio Bit Rate | 64 Kbps |
| Audio Compression | G.711u |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Recording Resolution | 1080p Lite/ 720p/ VGA/ WD1/ 4CIF/ CIF |
| Input Resolution | HDTVI: 1080p (25~30 fps), 720p (25~30 fps) HDCVI: 1080p (25~30 fps), 720p (25~30 fps) AHD: 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream Encoding | For 1080p stream: 1080p Lite/720p Lite/WD1/4CIF/VGA (15 fps), CIF (25 fps) For 720p stream: 720p/WD1/4CIF/VGA (15 fps), CIF (25 fps) For SD stream: WD1/4CIF/VGA/CIF (25 fps (P), 30 fps (N)) |
| Extra Stream Encoding | For 1080p and 720p stream: CIF/QVGA (15 fps) For SD stream: CIF/QVGA (25 fps (P), 30 fps (N)) |
| Video Bit Rate | 32 Kbps to 4 Mbps |
| Alarms | Not available |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. Available on all analog channels. |
| Internal Storage | 1 SATA 3.5" HDD of up to 10 TB (not included) |
| Communication | 2 x USB 2.0 (rear) / 1 x RJ45 (Ethernet) |
| Remote Connections | 128 |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power Supply | DC 12 V, 1.5 A, ≤ 18 W (without HDD) |
| Operating Temperature | -10° ~ +55° C |
| Dimensions / Weight | 45 (H) mm x 260 (W) mm x 222 (D) mm |
| Weight | ≤ 2.2 Kg (without HDD) |
The DS-7216HGHI-M1(F) is an excellent choice for installers looking to implement a robust surveillance system in retail environments or residential complexes. With its 16-channel capability, users can monitor multiple areas simultaneously, ensuring comprehensive coverage. The device's H.265 Pro+ compression technology allows for efficient storage management, enabling longer recording times without sacrificing video quality. Additionally, the motion detection 2.0 feature enhances security by providing alerts for human and vehicle movements, making it ideal for high-traffic areas. Installers can easily set up the system using the plug-and-play functionality, while end users benefit from remote access via web browsers or mobile apps, allowing them to monitor their premises from anywhere. This combination of features makes the DS-7216HGHI-M1(F) a versatile solution for modern surveillance needs.
