The iDS-E04HUHI-XB+4/1 ALM is a versatile 5-in-1 DVR designed for comprehensive video surveillance solutions. It supports multiple video formats including HDTVI, HDCVI, AHD, and CVBS, making it suitable for various installation environments. With its advanced features such as AcuSense technology for human and vehicle classification, this device is ideal for both residential and commercial applications, ensuring enhanced security and efficient monitoring.
| Brand | HIKVISION |
| Series | Value |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 4 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | 2 additional IP channels up to 8 MPx |
| Available Bandwidth | 96 Mbps |
| Video Outputs | 1 HDMI 2K and 1 VGA, simultaneous |
| Display Resolution | HDMI: 2560x1440, 1920x1080, 1280x1024, 1280x720 / 60 Hz VGA: 1920x1080, 1280x1024, 1280x720 / 60 Hz |
| Audio Inputs | Audio over coaxial on all BNC input channels |
| Audio Outputs | Audio output via HDMI |
| Audio Bit Rate | 64 Kbps |
| Audio Compression | G.711u |
| Video Compression | Analog channels: H.265 Pro / H.265 IP channels: H.265 |
| Recording Resolution | 8MPx / 5MPx / 3K / 4MPx / 3 MPx / 1080p/ 720p/ WD1/ 4CIF/ CIF |
| Input Resolution | HDTVI: 8MPx (12.5~15 fps), 5MPx (12.5~20 fps), 3K (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) HDCVI: 8MPx (12~15 fps), 5MPx (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) AHD: 5MPx (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream Encoding | 8MPx (8 fps), 3K (12 fps), 5MPx (12 fps), 4MPx Lite (15 fps), 3MPx (18 fps), 1080p/720p/WD1/4CIF (25 fps) |
| Extra Stream Encoding | WD1/4CIF/CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | Video bitrate adaptable according to scene type |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | 4 inputs / 1 output |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied to motion detection. Available on all analog channels. |
| Intelligent Functions | AcuSense, available on up to 4 channels. Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Entry Region, Exit Region |
| Recording Method | Manual, scheduled, motion detection |
| Internal Storage | 1 included eSSD of 1024 GB (960 GB available) |
| Communication | 2 x USB 2.0 (rear) / 1 x RJ45 (Ethernet) |
| Remote Connections | 32 |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Power Supply | DC 12 V, 1 A, ≤ 7.5 W (with eSSD) |
| Operating Temperature | -10° ~ +45° C |
| Dimensions | 46 (H) mm x 151 (W) mm x 121 (D) mm |
| Weight | ≤ 0.5 Kg (with eSSD) |
The iDS-E04HUHI-XB+4/1 ALM is ideally suited for small to medium-sized businesses looking to enhance their security infrastructure. For instance, a retail store can deploy this 5-in-1 DVR to monitor multiple entry points and high-traffic areas. With its motion detection 2.0 feature, the system can intelligently differentiate between human and vehicle movements, reducing false alarms and ensuring that security personnel are alerted only when necessary. The remote access capabilities allow store managers to monitor live feeds from their smartphones or PCs, providing peace of mind even when they are off-site. Additionally, the included eSSD storage ensures that high-resolution footage is securely stored, enabling easy retrieval during investigations. This combination of features makes the iDS-E04HUHI-XB+4/1 ALM an excellent choice for businesses aiming to implement a robust and efficient surveillance system.
Data sheet
Specific References
