| Brand | HIKVISION | |
| Range | Value | |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP | |
| Video inputs | 8 BNC Channels, (HDTVI / HDCVI / AHD / CVBS) | |
| Hybrid Configuration | 4 additional IP CH: Up to 12 IP channels (8Mpx), replacing all BNC channels Enhanced IP mode: 8 additional IP CH: Up to 16 IP Channels (4Mpx), replacing all BNC channels | |
| Available bandwidth | 128 Mbps | |
| Video outputs | 1 HDMI 4K and 1 VGA, simultaneous; | |
| Display resolution | HDMI: 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720 / 60Hz VGA: Audio inputs audio | 1 Channel RCA |
| Two-way audio | Reusing the audio input | |
| Audio Bit Rate | 64 Kbps | |
| Audio compression | G.711u | |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 IP: H.265+ / H.265 / H.264+ / H.264 | |
| Input resolution | HDTVI: 8Mpx (12.5~15 fps), 3K (5Mpx 16:9) (20 fps), 5Mpx (12~20 fps), 4Mpx (25~30 fps), 3Mpx (18 fps), 1080p (25~30 fps), 720p (25~60 fps) fps) AHD: 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC | |
| Main Stream Encoding | 8Mpx (8 fps), 3K (12 fps), 5Mpx (12 fps), 4Mpx (15 fps), 3Mpx (18 fps), 1080p /720p/WD1/4CIF/VGA/CIF (25 fps (P), 30 fps (N)) * 8Mpx@8 fps is only available for channel 1 | |
| Extra Stream Encoding | WD1/4CIF/CIF (25 fps (P), 30 fps (N)) | |
| Video Bit Rate | 32 Kbps at 10 Mbps | |
| Simultaneous multifunction | Pentaplex: Direct, Recording, Playback, Backup and Remote Access | |
| Alarms | Not available | |
| Artificial Intelligence | Motion Detection 2.0: Motion detection based on deep-learning can classify humans and vehicles based on motion detection. Enabled by default on all analog channels * Motion detection and AcuSense cannot be enabled at the same time on the same device. | |
| Smart Features | AcuSense: Perimeter protection based on VCA rules with false alarm filter for human and vehicle detection. Available in up to 4 channels of analog video * Motion detection and AcuSense cannot be enabled at the same time on the same device. | |
| Recording method | Manual, scheduled, motion detection | |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network | |
| Internal storage | 1 SATA 3.5" HDD up to 10 TB (not included) | |
| Communication | 2 x USB (Mouse and backup) / RJ45 (Ethernet) | |
| Remote Connections | 64 | |
| Remote Access | Web Browser, Hik-Connect Smartphone App, iVMS-4200 PC Software and Hik-Central | |
| Power | DC 12 V, 2 A, ≤ 10 W (without HDD) | |
| Operating Temperature | -10° ~ +55° C | |
| Dimensions / Weight | 45 mm (H) x 200 mm (W) x 200 mm (Fo) / ≤ 1 Kg (without HDD) | |
| Color | White |
Data sheet
