| Brand | X-Security |
| Image Sensor | 1/2.8” CMOS |
| Resolution | 1080p(1920x1080), 720p(1280x720), D1(704x576), CIF(352x288) |
| Compression | H.265+/H.265/H.264+/H.264 |
| Main Stream Rate | 1080p (1~25FPS) / 720p(1~50FPS) |
| Extra Stream Rate | 2nd: D1/CIF (1 ~ 25 FPS), 3rd: 720p/D1/CIF (1 ~ 25 FPS) |
| Bitrate | 25 Kbps ~ 6400 Kbps (H265) |
| Lens | 5 ~ 80 mm (16X optical zoom) Auto Focus |
| Infrared Range | 100 m |
| Minimum Illumination | 0.005 Lux (color) / 0.0005 Lux (B/W) |
| Image Enhancements | WDR (120dB), 3DNR, HLC, BLC, AGC, Privacy Mask, Smart Motion Detection (SMD) |
| Intelligent Video System (IVS) | Line crossing, Perimeter, Object lost/abandoned |
| Day/Night | Removable ICR mechanical filter |
| Network Interface | Ethernet 10/100 BaseT |
| Remote Access | WEB interface, CMS software, mobile app and NVR |
| Memory | Micro SD card slot (Max 512 GB) |
| Autotracking | Available |
| Autopatrol | Activates IVS rule when detecting a target and makes the camera link with the PTZ to rotate towards the target position and patrol according to its preset settings. |
| Facial Detection | Available and can activate autotracking |
| Pan/Tilt Range | Horizontal: 0°~360°, Vertical: -5°~90°, Auto flip 180° |
| Manual Speed | Horizontal: 0.1°~240° /s, Vertical: 0.1°~160° /s |
| Speed between Presets | Horizontal: 240° /s, Vertical: 160° /s |
| Predefined Positions | 300, 5 auto pattern, 8 auto tour, auto pan, 5 auto scan |
| Communication | DH-SD, ONVIF Compatible |
| Alarms | 2 inputs / 1 relay NO/NC |
| Audio | 1 input (Line In) / 1 output (Line Out) |
| Power | AC 12 V / 2 A , PoE+ IEEE802.3at |
| Protection Grade | IP66 |
| Operating Temperature | -40º C ~ +60º C |
| Dimensions | 170.4 mm (H) x 171 (Ø) mm |
| Weight | 3200 g |
Data sheet
