The DS-2CD1183G2-LIU(2.8mm) is a high-performance IP dome camera designed for effective surveillance in various environments. With its 8 Megapixel resolution and advanced features, this camera is ideal for both indoor and outdoor applications, providing clear images even in low-light conditions. Its robust design ensures durability, making it suitable for security installations in commercial and residential settings.
| Brand | HIKVISION |
| Series | Value |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Maximum Resolution | 8 Megapixel (3840x2160) |
| Main Stream Rate | 12.5 fps (3840x2160, 3200x1800, 2688x1520, 1920×1080, 1280×720) |
| Extra Stream Rate | 12.5 fps (1280x720, 640x480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Optics | 2.8 mm |
| Field of View (FOV) | H: 113°, V: 62°, D: 134° |
| DORI | 79 m (D), 31 m (O), 15 m (R), 7 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color: 0.01 Lux @(F2.0, AGC ON) 0 Lux with IR up to 30 m |
| Supplementary Lighting | Hybrid Light: IR up to 30 m White Light up to 30 m |
| Day/Night | Removable ICR Mechanical Filter |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror Function, Privacy Masking |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. |
| Internal Storage | Not available |
| Audio | Integrated Microphone |
| Audio Type | Mono |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power Supply | DC 12 V / 500 mA / 6 W max. / PoE IEEE802.3af |
| Protection Grade | IP67 Waterproof, IK08 Vandal Resistant |
| Material | Metal and Plastic |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | Ø 121.5 x 97.6 mm (H) |
| Weight | 550 g |
The DS-2CD1183G2-LIU(2.8mm) is an excellent choice for security professionals looking to enhance surveillance in retail stores, parking lots, or residential areas. With its high-resolution imaging and advanced motion detection capabilities, this camera can effectively monitor large areas while distinguishing between human and vehicle movements. The IP67 waterproof rating ensures reliable performance in various weather conditions, making it suitable for outdoor installations. Additionally, the camera's remote access features allow users to monitor live feeds via web browsers or mobile applications, providing peace of mind and flexibility. The integrated microphone adds an extra layer of security by capturing audio, which can be crucial for incident verification. Overall, the DS-2CD1183G2-LIU(2.8mm) is a versatile solution for comprehensive surveillance needs.
