The iDS-E04HUHI-XB is a versatile 5-in-1 DVR designed for high-definition video surveillance, supporting multiple formats including HDTVI, HDCVI, AHD, and CVBS. This compact and lightweight device is ideal for both residential and commercial applications, providing seamless integration with existing security systems. With advanced features such as AcuSense technology for human and vehicle classification, it enhances security monitoring while reducing false alarms.
| Brand | HIKVISION |
| Series | Value |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 4 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | 2 additional IP Channels up to 8 MPx |
| Available Bandwidth | 96 Mbps |
| Video Outputs | 1 HDMI 2K and 1 VGA, simultaneous |
| Display Resolution | HDMI: 2560x1440, 1920x1080, 1280x1024, 1280x720 / 60 Hz VGA: 1920x1080, 1280x1024, 1280x720 / 60 Hz |
| Audio Inputs | Audio over coaxial on all BNC input channels |
| Audio Outputs | Audio output via HDMI |
| Audio Bit Rate | 64 Kbps |
| Audio Compression | G.711u |
| Video Compression | Analog Channels: H.265 Pro / H.265 IP Channels: H.265 |
| Recording Resolution | 8MPx / 5MPx / 3K / 4MPx / 3 MPx / 1080p/ 720p/ WD1/ 4CIF/ CIF |
| Input Resolution | HDTVI: 8MPx (12.5~15 fps), 5MPx (12.5~20 fps), 3K (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) HDCVI: 8MPx (12~15 fps), 5MPx (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) AHD: 5MPx (20 fps), 4MPx (25~30 fps), 1080p (25~30 fps), 720p (25~30 fps) CVBS: PAL/NTSC |
| Main Stream Encoding | 8MPx (8 fps), 3K (12 fps), 5MPx (12 fps), 4MPx Lite (15 fps), 3MPx (18 fps), 1080p/720p/WD1/4CIF (25 fps) |
| Extra Stream Encoding | WD1/4CIF/CIF (25 fps (P), 30 fps (N)) |
| Video Bit Rate | Video bitrate adaptable according to scene type |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | Not available |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied to motion detection. Available on all analog channels. |
| Intelligent Functions | AcuSense, available on up to 4 channels. Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Entry Region, Exit Region |
| Recording Method | Manual, scheduled, motion detection |
| Internal Storage | 1 included eSSD of 1024 GB (960 GB available) |
| Communication | 2 x USB 2.0 (rear) / 1 x RJ45 (Ethernet) |
| Remote Connections | 32 |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power Supply | DC 12 V, 1 A, ≤ 7.5 W (with eSSD) |
| Operating Temperature | -10° ~ +45° C |
| Dimensions | 46 (H) mm x 151 (W) mm x 121 (D) mm |
| Weight | ≤ 0.5 Kg (with eSSD) |
The iDS-E04HUHI-XB is ideally suited for a variety of surveillance environments, including retail stores, offices, and residential properties. For instance, a retail store can deploy this 5-in-1 DVR to monitor customer activity and enhance security. With its motion detection 2.0 feature, the device can accurately identify human and vehicle movements, significantly reducing false alarms. The remote monitoring capabilities allow store managers to access live feeds and recorded footage from anywhere using the Hik-Connect app. Additionally, the included eSSD storage ensures ample space for high-resolution recordings, while the HDMI 2K output provides clear video playback on larger screens. This combination of features makes the iDS-E04HUHI-XB an excellent choice for those seeking a reliable and efficient security solution.
