| Brand | X-SECURITY |
| Maximum Resolution | 4 Megapixel (2560×1440) |
| Image Sensor | 1/2.9” Progressive CMOS |
| Lens | 2.7 mm–13.5 mm (H: 104°–29°; V: 54°–16°; D: 125°–34°) |
| IR Range | 60m |
| Main Stream Rate | 2688 × 1520@(1–20 fps)/2560 × 1440@(1-25/30 fps) |
| Extra Stream Rate | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| DORI | 64-210 (D), 25.6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Minimum Illumination | 0.006 lux@F1.5 (Color, 30 IRE) 0.0006 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) |
| Image Enhancements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter Protection) | Intrusion, line crossing (both functions support vehicle and person classification and accurate detection) |
| Smart Search | Work together with Smart NVR to refine smart search, event extraction, and event video merging |
| Network Interface | Ethernet 10/100 BaseT |
| Audio | 1 Input / 1 Output / Built-in Microphone |
| Alarms | 1-channel Input: 5 mA 3 V–5 V DC 1-channel Output: 300 mA 12 V DC |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Remote Access | WEB Interface, CMS (DSS/PSS), Smartphone, and NVR |
| Material | Metal |
| Interoperability | ONVIF (Profile S/Profile T); CGI |
| Power | DC 12 V / 3.1W, PoE IEEE802.3af |
| Operating Temperature | -30º C ~ +60º C |
| Protection Grade | IP67 Waterproof, IK10 Vandal-proof |
| Dimensions | 238.5 mm (L) x 90.7 mm (Ø) |
| Weight | 730 g |
