| Brand | HIKVISION |
| Range | VALUE |
| Image Sensor | 1/2.7“ Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Rate main stream | 25 fps (1920x1080, 1280x720) |
| Extra stream rate | 25 fps (640x480, 640x360) |
| Minimum illumination | Color: 0.01 Lux @ (F2.0, AGC ON) Black and white: 0 Lux with IR |
| Illumination | IR LEDs range 15 m |
| Day / Night | Removable ICR mechanical filter |
| Compression | H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Optics | 4 mm fixed lens |
| Viewing angle (FOV) | 90º (H), 48º (V), 107º (D) |
| DORI | 50 m (D), 20 m (W), 10 m (R), 5 m (I) |
| Image Enhancements | DWDR, BLC, HLC, 3D-DNR, Mirror Function |
| ANR | No |
| Motion Detection | Yes |
| Pan/Tilt Range | Horizontal: 0~350°, Vertical: -15°~100° |
| Manual speed | Horizontal: up to 20°/s, Vertical: up to 15°/s |
| Internal storage | MicroSD card slot up to 256 GB |
| Audio | Built-in microphone and speaker |
| Audio compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM |
| Audio bit rate | AAC: 16 Kbps, 32 Kbps, 64 Kbps; MP2L2: 32Kbps, 40Kbps, 48Kbps, 56Kbps, 64Kbps, 80Kbps, 96Kbps, 112Kbps, 128Kbps, 144Kbps, 160Kbps; G.711alaw: 64 Kbps |
| Alarms | Not available |
| PTZ control | Through network access |
| Network interface | Ethernet 10 / 100 BaseT |
| Remote access | Web Browser, Hik-Connect Smartphone App, iVMS-4200 PC Software and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power | DC 5 V / 5.5 W max. / PoE IEEE802.3af |
| Temp. operation | -10º C ~ +40º C |
| Protection degree | IP54 |
| Dimensions (without support) | 143 (H) mm x 93.5 mm (W) x 127 mm (D) |
| Weight (without stand) | 275 g |
Data sheet
