| Brand | X-SECURITY |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Maximum Resolution | 4 Megapixel (2688x1520) |
| Lens | 2.8 mm (H: 109º) XS-IPMC004SW-4U-L4 |
| Main Stream Rate | 2592×1944 (1–20 fps ), 2688×1520 (1–25 fps ) |
| Extra Stream Rate | Sub stream: 704×576, 704×480 (1–25 fps) Third stream: 1920×1080 (1–25 fps) |
| Minimum Illumination | Color 0.005 Lux @ F2.0 B/W 0.0005 Lux @ F2.0 |
| Image Enhancements | WDR(120dB), ROI, AWB, 3DNR, MD, Mask, Mirror |
| Compression | H.265+/H.265/H.264+/H.264 |
| Image Enhancements | BLC, HLC, DWDR, AWB, AGC, 3D-NR, MD, ROI, Mirror, Privacy Masking |
| Day/Night | Automatic electronic filter |
| Intelligent Functions | Face detection, line crossing, intrusion, scene changes, and audio detection |
| Network Interface | Ethernet 10/100 BaseT |
| Internal Storage | SD Card Slot, Max 128 GB |
| Alarms | 2 Input / 2 Relay |
| Audio | 1 Input / 1 Output |
| Remote Access | WEB interface, CMS (DSS/PSS), Smartphone and NVR |
| Interoperability | ONVIF |
| Power | DC 12 V / 5.1W mA, PoE IEEE802.3af |
| Operating Temperature | -40º C ~ 60º C |
| Protection Rating | Indoor |
| Unit Dimensions | 110 mm (H) x 83 (W) x 24 (D) mm |
| Weight | 210 g |
