- Hikvision
- PRO Series IP Dome Camera
- 6 Megapixel Resolution (3200x1800)
- 2.8 mm Lens | PoE | Alarms | Audio
- IR Range 30 m | Motion Detection 2.0
- AcuSense | Face Detection | IP67, IK10
Description & Key Features: DS-2CD2163G2-IS(2.8mm)
The DS-2CD2163G2-IS(2.8mm) is a high-performance IP dome camera designed for comprehensive surveillance in various environments. With its advanced features, this camera is ideal for both indoor and outdoor applications, providing exceptional image quality and reliable performance. The device is equipped with a 6 Megapixel sensor, ensuring clear and detailed video footage, even in low-light conditions. Its IR range of 30 meters allows for effective night vision, making it suitable for 24/7 monitoring. The camera's AcuSense technology enhances motion detection capabilities, reducing false alarms and improving security efficiency.
- Hikvision
- PRO Series
- IP Dome Camera
- 1/2.4" Progressive Scan CMOS
- 6 Megapixel (3200x1800)
- 2.8 mm Lens
- 0 Lux
- IR Range 30 m
- Compression H.265+ / H.265 / H.264+ / H.264
- Motion Detection 2.0
- AcuSense, false alarm filter for vehicles and people (line crossing and area intrusion)
- Face Detection
- WDR (120 dB)
- 3D-DNR
- Alarms
- Audio
- MicroSD card slot up to 512 GB
- WEB interface, CMS, Smartphone, and NVR
- ONVIF compatible
- PoE (IEEE802.3af)
- IP67 Waterproof
- IK10 Vandal Resistant
Specifications: DS-2CD2163G2-IS(2.8mm)
| Brand | HIKVISION |
| Series | PRO |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Maximum Resolution | 6 Megapixel (3200x1800) |
| Main Stream Rate | 25 fps (3200x1800, 2688x1520, 1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (1280x720, 640x480, 640×360) |
| Third Stream Rate | 10 fps (1920×1080, 1280×720, 640x480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Optics | 2.8 mm |
| Field of View (FOV) | H: 105°, V: 55°, D: 127° |
| DORI | 76 m (D), 30 m (O), 15 m (R), 7 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with IR range 30 m |
| Day/Night | Removable ICR mechanical filter |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror function, Privacy masking |
| ANR | Yes |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Intelligent Functions | AcuSense Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Face Detection | Yes |
| Alarms | 1 input / 1 relay |
| Audio | 1 input / 1 output |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
| Internal Storage | MicroSD card slot up to 512 GB |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF, ISAPI |
| Power Supply | DC 12 V / 500 mA / 6 W max. / PoE IEEE802.3af |
| Protection Grade | IP67 Waterproof, IK10 Vandal Resistant |
| Material | Body: Aluminum Alloy Dome: Plastic |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | Ø 110.8 mm x 84.7 mm (H) |
| Base Dimensions | Ø base 110.8 mm / Ø between screws 100.4 mm / 3 screws |
| Weight | 400 g |
Package Contents
- Hikvision IP Dome Camera
- Installation Material
- User Instructions
Use Case
The DS-2CD2163G2-IS(2.8mm) is perfectly suited for deployment in retail stores, parking lots, and office buildings, where security is paramount. Installers can leverage its plug-and-play capabilities for quick setup, ensuring minimal downtime. The camera's remote monitoring features allow users to access live feeds from anywhere via the Hik-Connect app, enhancing situational awareness. With its motion detection and AcuSense technology, the camera intelligently distinguishes between human and vehicle movements, significantly reducing false alarms. This is particularly beneficial in high-traffic areas, where unnecessary alerts can lead to alarm fatigue. Additionally, the camera's robust IP67 waterproof and IK10 vandal-resistant ratings ensure durability in various environmental conditions, making it a reliable choice for outdoor surveillance. Overall, the DS-2CD2163G2-IS(2.8mm) provides a comprehensive security solution that meets the demands of modern surveillance needs.
Data sheet
- Brand
- HIKVISION
- Resolution
- 6 Mpx
- Technology
- IP
- WDR
- WDR (120 dB)
- IR Distance
- 30 m
- Audio
- 1 Entrada / 1 Salida
- SD Slot
- Ranura MicroSD hasta 512 GB
- Wi-Fi
- No dispone
- IP Rating
- IP67
- IK Rating
- IK10
- Series
- PRO
- POE
- PoE (IEEE802.3af)
- Lens
- 2.8 mm
- Compatible models
- DS-1280ZJ-DM18,DS-1280ZJ-DM18,DS-1276ZJ-SUS,DS-1276ZJ-SUS,DS-1275ZJ-SUS,DS-1275ZJ-SUS,DS-1272ZJ-110B,DS-1272ZJ-110B,DS-1272ZJ-110,DS-1272ZJ-110,DS-1271ZJ-110,DS-1271ZJ-110,DS-1259ZJ,DS-1259ZJ,DS-1250ZJ,DS-1250ZJ
Specific References
- EAN13
- 6941264095460
