| Brand | Hikvision |
| Range | Value |
| Image sensor | 2 Mpx CMOS |
| Maximum resolution | 1080p (1920x1080) at 30 fps |
| Resolution | 1080p (25~30 fps) |
| Lens | Motorized varifocal lens 2.7~13.5 mm |
| Angle of view (FOV) | 102~31º (H) |
| Minimum illumination | 0.005 Lux@(F1.2, AGC ON) |
| Infrared illumination | 0 Lux / (Smart EXIR IR range 70 m) |
| Day / Night | Auto / Color / Black and White (ICR) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Using Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | WDR (120 dB), BLC, HLC, 3DNR, AGC, Mirror function, Smart IR |
| Communication | HIKVISION-C |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / AC 24 V / 9.7 W max. |
| Protection degree | Waterproof IP67, vandal-resistant IK10 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 145 mm x 111.3 mm (Al) |
| Base diameter | Ø base 139.9 .mm / Ø between screws 130 mm / 3 screws |
| Weight | 870 g |
