| Brand | Hikvision | ||
| Range | Value | ||
| Image Sensor | High Performance CMOS Ultra Low Light | ||
| Resolution maximum | 1080p (1920x1080) at 30 fps | ||
| Resolution | TVI: 1080p (25~30 fps) CVI: 1080p (25~30 fps) AHD: 1080p (25~30 fps) CVBS: PAL/NTSC class="table-data"> | Angle of view (FOV) | 102º ~ 31º (H) |
| Minimum illumination | 0.005 Lux @ (F1.2, AGC ON) | ||
| Infrared illumination | 0 Lux / (EXIR 2.0 IR Range 70 m) | ||
| Day / Night | Auto / Color / Black and white (ICR) | ||
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS | ||
| Video output switching | Via Switch | ||
| Basic functions | OSD menu (remote) | ||
| Configurable OSD functions | WDR (120 dB), BLC, HLC, 3DNR, AGC, AWB, Mirror function, Smart IR | ||
| Communication | HIKVISION-C | ||
| Lens Positioning | 3 Axis | ||
| Power | DC 12 V / 7.7 W max. | ||
| Protection degree | Waterproof IP67 | ||
| Temp. operation | -40º C ~ +60º C | ||
| Material | Metal | ||
| Dimensions | 110.2 mm (H) x 123.9 mm (w) >Weight | 600 g |
