| Brand | Hikvision |
| Gamma | Value |
| Image Sensor | 5Mpx CMOS |
| Maximum resolution | 5 Megapixel (2560x1944) at 20 fps |
| Resolution | 5Mpx (20 fps), 4Mpx (25~30 fps), 1080p (25~30 fps) |
| Lens | Motorized varifocal lens 2.7~13.5 mm |
| Angle of view (FOV) | 95~26º (H), 72~20º (V), 126~33º (D) |
| Minimum Illumination | 0.01 Lux @ (F1.2, AGC ON) |
| Infrared Illumination | 0 Lux / (Smart IR scope 40 m) |
| Day / Night | Auto / Color / Black and White (ICR) |
| Video output | 1 x BNC HDTVI |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, BLC, HLC, 2DNR, AGC, AWB, Smart IR |
| Communication | HIKVISION-C |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 8.4 W max. PoC.at (power over coaxial cable) |
| Protection degree | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 123.87 mm x 110.24 mm (H) x 134.3 mm (Fo) |
| Base diameter | base Ø 123.87 mm / Ø between screws 90 mm / 3 screws |
| Weight | 595 g |
