The Hikvision Pro Series with ColorVu 3.0 redefines video surveillance with full-color images, even in low-light environments. This device is ideal for security monitoring in various settings, such as retail stores, parking lots, and residential areas. Its advanced sensor and lens technology capture more light, providing enhanced clarity and detail without the need for additional lighting. The integration of HikAI-ISP, an intelligent image processor, optimizes visual quality by reducing noise and improving sharpness in challenging conditions.
The AcuSense 3.0 technology allows for precise detection of humans and vehicles, making it a valuable asset for intelligent surveillance systems.
| Brand | HIKVISION |
| Series | PRO |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Maximum Resolution | 8 Megapixel (3840x2160) |
| Main Stream Rate | 25 fps (3840x2160, 3200x1800, 2688x1520, 1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (1280×720, 640×480, 640×360) |
| Third Stream Rate | 10 fps (1920x1080, 1280x720, 640×480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Lens | Motorized 2.8-12 mm |
| Field of View (FOV) | H: 112.3-41.2°, V: 58.1-23.1°, D: 137.4-47.3° |
| DORI | WIDE: 89.2 m (D), 35.4 m (O), 17.8 m (R), 8.9 m (I) TELE: 220.0 m (D), 87.3 m (O), 44.0 m (R), 22.0 m (I) |
| Minimum Illumination | Color: 0.0005 Lux @(F1.2, AGC ON) |
| ColorVu 3.0 | Color image 24/7 with HikAI-ISP, F1.2, and 1/1.8" sensor AI noise reduction offers the advantage of higher static brightness Dynamic motion blur reduction, providing sharp image quality even in low-light conditions |
| Hybrid Light | IR and White Light up to 60m |
| Day/Night | Auto / Manual / Programmable |
| Audio | 1 Input / 1 Output |
| Image Enhancements | AI WDR (130 dB), BLC, HLC, 3D-DNR, AWB, ROI, Mirror function, Privacy masking |
| ANR | Yes |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. * Motion Detection 2.0, Face Recognition, and AcuSense cannot be enabled simultaneously. Enabling one function will disable the other two. |
| Intelligent Functions | AcuSense 3.0: Enhances detection effectiveness by analyzing the scene and generating alarms for objects that recently entered the scene, Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion, Area Entry, and Area Exit. * Motion Detection 2.0, Face Recognition, and AcuSense cannot be enabled simultaneously. Enabling one function will disable the other two. |
| Face Recognition | Face Capture * Motion Detection 2.0, Face Recognition, and AcuSense cannot be enabled simultaneously. Enabling one function will disable the other two. |
| AcuSearch | Yes (Requires recorder for searches) |
| Internal Storage | MicroSD card slot up to 512GB |
| Alarms | 1 Input / 1 Output (max. 24 VDC/24 VAC, 1 A) |
| Network Interface | Ethernet 10/100M BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Power Supply | DC 12 V / 1.08A / 13W max. / PoE IEEE802.3at |
| Protection Grade | IP67 waterproof, IK10 vandal-proof, NEMA 4X (Corrosion protection) |
| Operating Temperature | -30º C ~ +60º C |
| Dimensions | 140 mm (W) x 140 mm (H) x 333.8 mm (D) |
| Weight | 1540 g |
In a typical deployment scenario, the DS-2CD2687G3-LIZSY(2.8-12mm) camera can be installed in a retail environment to enhance security monitoring. With its ColorVu 3.0 technology, the camera provides clear, full-color images even at night, ensuring that all activities are captured in detail. The motion detection capabilities, enhanced by AcuSense 3.0, allow for accurate identification of human and vehicle movements, significantly reducing false alarms. This feature is particularly beneficial in busy shopping areas where foot traffic is high. Additionally, the camera's remote access capabilities enable security personnel to monitor live feeds from anywhere, ensuring a rapid response to any incidents. The robust design, rated IP67 and IK10, ensures that the camera withstands harsh weather conditions and potential vandalism, making it a reliable choice for outdoor installations. Overall, the DS-2CD2687G3-LIZSY(2.8-12mm) camera is an excellent solution for businesses looking to enhance their security infrastructure.
