| Brand |
X-Security |
| Video Format |
HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs |
32 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration |
Up to 32 IP Channels (6Mpx), replacing all BNC channels |
| Video Outputs |
1 HDMI 4K, 1 VGA |
| Video/Audio Compression |
H.265+/H.265/H.264+/H.264 / G.711u |
| Display Resolution |
3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Total Bandwidth |
128 Mbps |
| Recording Resolution |
5M-N, 4 M-N, 1080p, 720p, 960H, D1, CIF |
| Main Stream Encoding |
5M-N(10 fps), 4M-N/1080p(15 fps), 720p (30 fps) |
| Extra Stream Encoding |
D1 / CIF / QCIF (1~15 FPS) |
| Simultaneous Functions |
Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Audio |
1 in / 1 out RCA |
| Bidirectional Audio |
Using audio input/output |
| Video Analysis |
IVS: Line Crossing | Intrusion in Area | Abandoned Object | Face Detection
IP Mode, Facial Recognition, and IVS cannot be activated simultaneously |
| Intelligent Functions |
P2P Function | POS Function | Alarm/Audio/Coaxial Update (All-over-Coax) |
| Intelligent Motion Detection |
Up to 16 channels capable of classifying targets between humans and vehicles |
| Recording Method |
Manual, Scheduled, Motion Detection, Alarm, Stop |
| Backup |
USB / Network |
| Internal Storage |
2 SATA HDD up to 16TB each (not included) |
| Communication |
RS485 (PTZ) /3 x USB (Mouse and Backup) / RJ45 10/100/1000 (Ethernet) |
| Remote Access |
Browser, Mobile App, or PSS Software |
| Power |
DC 12V / 5A |
| Dimensions / Weight |
288 (H) x 375 (W) x 53 (D) mm / 2.0 Kg |
