| Brand | X-Security |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 8 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | Up to 10 IP Channels (6Mpx), replacing all BNC channels |
| Video Outputs | 1 HDMI full HD and 1 VGA |
| Audio Inputs | 1 RCA Channel |
| Audio Outputs | 1 RCA Channel |
| Bidirectional Audio | Reusing audio input/output |
| Video/Audio Compression | H.265+/H.265/H.264+/H.264 |
| Display Resolution | 1920x1080, 1280x1024, 1280x720 |
| SMD PLUS | Filter for false alarms of people and vehicles in motion detection |
| Recording Resolution | 1080N; 720p; 960H; D1; HD1; BCIF; CIF |
| Main Stream Encoding | First channel: 1080N, 720p (1~25/30FPS), Rest of channels: 1080N, 720p (1~15FPS) / 960H, D1, CIF (1~25/30 FPS) |
| Extra Stream Encoding | CIF (1~7 FPS) |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Intelligent Functions | POS Function | Bidirectional Audio via RCA |
| Alarms | Not available |
| Recording Method | Manual, scheduled, motion detection (up to 396 zones) |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal Storage | 1 HDD SATA 3.5" up to 6TB (not included) |
| Communication | 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote Access | Browser (ActiveX), Mobile App, or PSS Software |
| Power | DC 12 V / 1.5 A |
| Dimensions / Weight | 47.6 (H) x 260 (W) x 237.9 (D) mm / 0.89 Kg |
