5n1 X-Security Video Recorder XS-XVR6116-4KL-2FACE-V2
Brand: X-SECURITY
- 5-in-1 X-Security Video Recorder
- 16 CH HDTVI / HDCVI / AHD / CVBS / 16+16 IP
- 4KL (7FPS) / 5M (12FPS) / 4M/3M (15FPS)
- 1080P/720P (25FPS) | 1 CH audio
- HDMI 4K and VGA output
Video Recorder 5n1 X-Security XS-XVR6116-4KL-2FACE-V2
- X-Security
- DVR 5n1
- 16 CH video HDTVI/HDCVI/AHD/CVBS / 16+16 CH IP / 1 CH audio
- H.265+/H.265
- Integrates AI functions
- Resolution on all channels 4K@ (1-7 fps); 6 MP@ (1-10 fps); 5 MP @ (1-12 fps); 4K-N/4 MP/3 MP@ (1-15 fps); 4M-N/1080P/720P/960H/D1/CIF (1 fps–25/30 fps) in all technologies
- PTZ control (RS485/Coaxial)
- Audio
- HDMI 4K and VGA output
- Mouse
- Space for 1 HDD
Technical Specifications
| Brand | X-Security |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 16 BNC Channels: HDTVI: Up to 5Mpx HDCVI: Up to 4K AHD: Up to 5Mpx CVBS |
| Hybrid Configuration | Up to 32 IP Channels (8Mpx), replacing all BNC channels |
| Video Outputs | 1 HDMI Full HD, 1 VGA |
| Audio Inputs | 1 RCA Channel |
| Audio Outputs | 1 RCA Channel |
| Two-way Audio | Reusing audio input/output |
| Audio Support | Over coaxial |
| Video Compression | H.265+; H.265; H.264+;H.264 |
| Display Resolution | 3840x2160, 2560x1440, 1920x1080, 1280x1024, 1280x720, 1024x768 |
| Total Bandwidth | 96 Mbps |
| Recording Resolution | 4K / 6Mp / 5Mp / 4Mp / 3Mp / 1080p / 1080N / 720p |
| Main Stream Encoding | All channels 4K@ (1-7 fps); 6 MP@ (1-10 fps); 5 MP @ (1-12 fps); 4K-N/4 MP/3 MP@ (1-15 fps); 4M-N/1080P/720P/960H/D1/CIF (1 fps–25/30 fps); |
| Extra Stream Encoding | 960H@ (1 fps–15 fps); D1/CIF@ (1 fps–25/30 fps) |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | Not available |
| AI Alarms | Face detection, face recognition, perimeter protection |
| Video Analysis | VCA: Line crossing | Intrusion in area | Abandoned object | Face detection |
| Recording Method | Manual, scheduled, motion detection, alarm |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal Storage | 1 SATA HDD up to 8 TB |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote Access | Browser (ActiveX), Mobile phone application or PSS software |
| Power Supply | DC 12 V / 3 A |
| Dimensions / Weight | 55 (H) x 325 (W) x 255 (D) mm / 2 Kg |
Content
- 5 in 1 X-Security Recorder
- Mouse
- AC/DC Adapter 12 V / 3.0 A
- Ethernet Cable
