| Brand | X-Security |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 8 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | Up to 12 IP Channels (6Mpx), replacing all BNC channels |
| Video Outputs | 1 HDMI 1080p, 1 VGA |
| Video/Audio Compression | H.265+/H.265/H.264+/H.264 |
| Display Resolution | 1920x1080, 1280x1024, 1280x720 |
| Total Bandwidth | 64 Mbps |
| Recording Resolution | 5 M-N, 4 M-N,1080p, 1080N, 720p, 960H, D1, CIF |
| Main Stream Encoding | 5M-N(10 FPS); 4M-N/1080p(15 FPS); 1080N / 720p / 960H / D1 / CIF (25/30 FPS) |
| Extra Stream Encoding | D1 / CIF (1~15 FPS) |
| Simultaneous Function | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Audio Inputs | 8 RCA Channel / 8 BNC Channel (Audio over Coaxial) |
| Audio Outputs | 1 RCA Channel |
| Bidirectional Audio | Using audio input/output |
| Alarms IN/OUT | 8 IN/ 3 Relay |
| Video Analysis | IVS: Line Crossing | Intrusion in Area | Abandoned Object | Face Detection IP Mode, Face Recognition, and IVS cannot be activated simultaneously |
| Face Recognition | Up to 1 analog face comparison channel live |
| Intelligent Motion Detection | Up to 8 channels capable of classifying targets between humans and vehicles |
| Recording Method | Manual, scheduled, motion detection, alarm |
| Backup | USB/ Network |
| Internal Storage | 1 HDD SATA 3.5" up to 16 TB (not included) |
| Communication | RS485 (PTZ) /2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote Access | Browser (ActiveX), Mobile App, or PSS Software |
| Power Supply | DC 12V / 2A |
| Dimensions / Weight | 55 (H) x 325 (W) x 257 (D) mm / 1.2 Kg |
Data sheet
