| Brand | X-Security |
| Video Format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video Inputs | 4 BNC Channels (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid Configuration | Up to 8 IP Channels (8Mpx), replacing all BNC channels |
| Video Outputs | 1 4K HDMI, 1 VGA |
| Video/Audio Compression | H.265+ / H.265 / H.264+ / H.264 |
| Display Resolution | HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Total Bandwidth | 64 Mbps |
| Recording Resolution | 8M (7FPS) / 6M (10FPS) / 5M (12FPS) / 4K-N, 4MP, 3MP(15fps) / 4M-N, 1080P, 720P, 960H, D1, CIF (25/30fps) |
| Main Stream Encoding | 8M (7FPS) / 6MP(10FPS) / 5MP(12FPS) / 4K-N, 4MP, 3MP(15FPS) / 4M-N, 1080P, 720P, 960H, D1, CIF (25/30FPS) |
| Extra Stream Encoding | 960H(15FPS) / D1, CIF(25/30FPS) |
| Simultaneous Function | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Audio Inputs | 4 RCA Channels |
| Audio Outputs | 1 RCA Channel |
| Bidirectional Audio | Using audio input/output |
| Alarms IN/OUT | 8 / 3 |
| Video Analysis | IVS: Face Detection / Human and Vehicle Recognition / Line Crossing / Intrusion |
| Facial Recognition | 1 analog channel for live face comparison |
| Intelligent Motion Detection | Up to 4 channels capable of classifying targets between humans and vehicles |
| Recording Method | Manual, scheduled, motion detection, alarm |
| Backup | USB/Network |
| Internal Storage | 1 SATA 3.5" HDD up to 10 TB (not included) |
| Communication | RS485 (PTZ) / 2 x USB (Mouse and backup) / RJ45 10/100 (Ethernet) |
| Remote Access | Browser (ActiveX), Mobile App, or PSS software |
| Power | DC 12V / 2A |
| Dimensions / Weight | 55 (H) x 325 (W) x 256.6 (D) mm / 1.1 Kg |
