PTZ IP camera range I1 Artificial Intelligence SF-IPSD5040ITA-4I1
Brand: SAFIRE SMART
- Safire Smart
- IP PTZ camera range I1 Artificial Intelligence
- Resolution 4 Megapixel (2560x1440) | WDR 120 dB
- 40X optical zoom | IR 350m
- Autotracking, human and vehicle | Alarms
- IP67 waterproof & IK10 | PoE+ (IEEE802.3at)
IP PTZ camera I1 range Artificial Intelligence SF-IPSD5040ITA-4I1
- Safire Smart
- I1 range with Advanced Artificial Intelligence
- IP PTZ camera
- 1/2.8" Progressive Scan CMOS
- 4 Megapixel (2560x1440)
- 40X optical zoom
- Lens 4.5-180 mm
- 0 Lux
- IR range 350 m
- WDR 120 dB
- H.265+ / H.264+ compression
- WDR
- 3DNR
- Artificial Intelligence for classification of human and vehicle
- Intelligent autotracking, tracking of humans and vehicles
- Facial recognition with capture of up to 17 faces at a time
- Audio
- Alarm
- WEB interface, CMS, Smartphone and NVR
- ONVIF compatible
- PoE+ (IEEE802.3at)
- Waterproof IP67
- IK10 vandal-proof
- Support included
Technical specifications
| Brand | Safire Smart |
| Gamma | I1 with Advanced Artificial Intelligence |
| Image Sensor | 1/2.7“ Progressive Scan CMOS |
| Resolution | 4 Megapixel (2560x1440) |
| Main Stream | 2560×1440,1920×1080,1280×960,1280×720 |
| Sub stream | 704x576, 640x480, 352x288 |
| Third Stream | 1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288 |
| Video Bit rate | 64Kbps ~ 8Mbps |
| Minimum Illumination | Color: 0.005 Lux @(F1.2, AGC ON), 0 Lux with IR |
| IR LED | 350m (850nm) |
| Compression | H.265+/ H.265 / H.264+/ H.264 |
| Optical Zoom | 40X |
| Digital Zoom | 16X |
| Lens | 4.5 - 180 mm |
| FOV | H: 55º - 2.4º / V: 33º - 1.4º / D: 61.5º - 2.8º |
| DORI | W: 100 m (D), 40 m (W), 20 m (R), 10 m (L) T: 3600 m (D), 1429 m (W), 720 m (R), 360 m (L) |
| Electronic shutter | 1/1s~1/10,000s |
| Day / Night | Removable ICR mechanical filter |
| Image enhancements | BLC, HLC, WDR, 3D-NR, AGC, AWB, MD, Privacy Masking, ROI |
| WDR | 120 dB |
| Advanced Functions | Artificial intelligence based on human and vehicle classification on: Area intrusion, Line crossing, traffic region input, output region. Face recognition with face capture of up to 17 faces at a time. |
| Intelligent Autotracking | Intelligent Human and Vehicle Tracking |
| Pan/Tilt Range | Horizontal: 360°, Vertical: -25°~155° auto flip |
| Manual speed | Horizontal: 0.1° ~ 390° /s, Vertical: 0.1° ~270° /s |
| Speed between Presets | Horizontal: 420° /s, Vertical: 300° /s |
| Preset positions | 360 Preset, 8 Tours, 4 Patrols |
| Internal storage | MicroSD Card, Max 256 GB |
| Audio | 1 Input / 1 Output |
| Audio compression | G.711 A/U |
| Audio bit rate | 64 Kbps |
| Alarms | 1 Input / 1 Relay |
| PTZ Control | Through network access |
| Network interface | Ethernet 10 / 100M BaseT |
| Remote Access | Web Browser, Safire Smart Smartphone App, Safire Smart VMS PC Software |
| Interoperability | ONVIF, PSIA, CGI |
| Power | DC 24 V / 3A, PoE+ IEEE802.3at |
| Temp. operation | -40º C ~ +70º C |
| Protection degree | IP67, IK10 / Surge 6000V |
| Dimensions (without support) | 197 (H) x 302(Ø) mm |
| Weight (without support) | 3000 g |
Contents
- Safire Smart IP PTZ Camera I1
- Installation material
- Wall bracket
- Quick installation guide
