| Brand | X-SECURITY |
| Maximum Resolution | 8 Megapixel (2688x1520) |
| Image Sensor | 1/2.7” Progressive CMOS |
| Lens | 2.7 mm–13.5 mm (H: 113°–31°; V: 58°–18°; D: 138°–36°) |
| IR Range | 40 m |
| Main Stream Rate | 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps) |
| Extra Stream Rate | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| DORI | 85.3-280 (D), 34.1-112 (O), 17.1-56 (R), 8.5-28 (I) |
| Minimum Illumination | 0.008 lux@F1.5 (Color, 30 IRE) 0.0008 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) |
| Image Enhancements | WDR 120 dB, BLC, HLC, AWB, AGC, 3D-NR, ROI , Smart IR |
| IVS (Perimeter Protection) | Intrusion, line crossing (both functions support vehicle and person classification and accurate detection) |
| Smart Search | Work together with Smart NVR to refine smart search, event extraction, and event video merging |
| Network Interface | Ethernet 10/100 BaseT |
| Audio | Built-in Microphone |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Remote Access | WEB Interface, CMS (DSS/PSS), Smartphone, and NVR |
| Material | Metal |
| Interoperability | ONVIF (Profile S/Profile T); .CGI; P2P; Hik-Connect |
| Power | DC 12 V / 3.6W, PoE IEEE802.3af |
| Operating Temperature | -30º C ~ +60º C |
| Protection Rating | IP67 Waterproof |
| Dimensions | 108.3 mm (D) x 122 mm (Ø) |
| Weight | 700 g |
