The DS-2CD1041G2-LIU(4mm) is a high-performance IP bullet camera designed for effective surveillance in various environments. With its 4 Megapixel resolution and advanced features, it is ideal for both indoor and outdoor applications, ensuring clear image quality and reliable monitoring. This camera is equipped with a hybrid light system that combines infrared and white light, making it suitable for low-light conditions. Its IP67 waterproof rating ensures durability against harsh weather, making it a perfect choice for security installations.
| Brand | HIKVISION |
| Series | Value |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Maximum Resolution | 4 Megapixel (2560x1440) |
| Main Stream Rate | 20 fps (2560x1440), 25 fps (1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (1280×720, 640x480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Optics | 4 mm |
| Field of View (FOV) | H: 82°, V: 45°, D: 98° |
| DORI | 53 m (D), 21 m (O), 10 m (R), 5 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color: 0.01 Lux @(F2.2, AGC ON) 0 Lux with IR |
| Supplementary Lighting | Hybrid Light: IR and White Light IR Range 20 m White Light Range 15 m |
| Day/Night | Removable ICR Mechanical Filter |
| Image Enhancements | DWDR, BLC, HLC, 3D-DNR, AGC, AWB, ROI, Mirror Function, Privacy Masking |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. |
| Audio | Integrated Microphone |
| Audio Type | Mono |
| Audio Compression | G.711ulaw/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC) |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 |
| Interoperability | ONVIF (Profile S, T), ISAPI, SDK |
| Power Supply | DC 12 V / 420 mA / 5 W max. PoE IEEE802.3af |
| Protection Rating | IP67 Waterproof |
| Material | Plastic |
| Operating Temperature | -30º C ~ +45º C |
| Dimensions | 57.9 mm (H) x 60.9 mm (W) x 138.8 mm (D) |
| Base Dimensions | Ø base 70 mm / Ø between screws 55 mm / 3 screws |
| Weight | 175 g |
The DS-2CD1041G2-LIU(4mm) is ideally suited for a variety of surveillance applications, including retail stores, parking lots, and residential areas. For instance, in a retail environment, this 4 Megapixel camera can be strategically placed at entrances and checkout areas to monitor customer activity and deter theft. The hybrid light system ensures that the camera captures clear images even in low-light conditions, enhancing security during nighttime hours. Additionally, the remote monitoring capabilities allow store managers to access live feeds via a smartphone app, providing real-time oversight. The motion detection feature, with human and vehicle classification, enables the camera to alert users to potential security breaches, ensuring prompt responses. With its IP67 waterproof rating, the camera can also be installed outdoors without concerns about weather damage, making it a versatile choice for comprehensive security solutions.
