X-Security NVR XS-NVR3832A-WIZ

Name: X-Security NVR XS-NVR3832A-WIZ
Brand: X-SECURITY
Price: 635.535 EUR
Availability: InStock

Brand: X-SECURITY

SKU: XS-NVR3832A-WIZ

Condition: New product

X-Security NVR
Maximum resolution 16 Megapixel
32 CH
Compression H.265 / H.264 | 8 HDD
HDMI 4K output | Alarm outputs

More details

Rating: Sign in to write a review

Overview
Data sheet
Reviews (0)

Overview

X-Security NVR XS-NVR3832A-WIZ

X-Security
NVR Recorder for IP cameras
32 CH of video
Maximum resolution 16 Megapixel
Smart Compression H.265+ / H.264
Alarm inputs and outputs
VGA and HDMI 4K output
Space for 8 HDD
Supported bandwidth 256 Mbps
SMD Plus: Advanced motion detection based on human and vehicle (Up to 4CH by the NVR itself)
IVS WizSense: Human and vehicle classification (Up to 2CH by the NVR itself)
Facial recognition (Up to 1CH by the NVR itself)
QuickPick: Smart search for a specific target based on human and vehicle from SMD events
Smart target search
Compatible with ONVIF

Technical Specifications

Brand	X-SECURITY
IP camera inputs	LAN port up to 32 channels
Compatible IP cameras	X-SECURITY (proprietary protocol), ONVIF
Video outputs	1 HDMI 4K, 1 VGA
Video compression format	H.265+ Smart / H.265 / H.264+ / H.264 / MJPEG
Bidirectional audio	1 input, 1 output, RCA
Recording resolution	16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p, D1, CIF
Decoding capacity	AI Disabled: 2CH at 16MP@30FPS, 2CH at 12MP@30FPS, 4CH at 8MP@30FPS, 4CH at 6MP@30FPS, 6CH at 5MP@30FPS, 8CH at 4MP@30FPS, 12CH at 1080p@30FPS, 16CH at 720p@30FPS, 32CH at D1@30FPS AI Enabled: 1CH at 16MP@30FPS, 2CH at 12MP@30FPS, 3CH at 8MP@30FPS, 3CH at 6MP@30FPS, 4CH at 5MP@30FPS, 6CH at 4MP@30FPS, 12CH at 1080p@30FPS, 16CH at 720p@30FPS, 32CH at D1@30FPS
Video output	1 HDMI up to 4K 1 VGA up to 1080P
Display resolution	HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920x1080, 1280×1024, 1280×720 *HDMI and VGA output can be configured simultaneously or independently
Bandwidth	AI Disabled: 256 Mbps input / 256 Mbps output AI Enabled: 180 Mbps input / 180 Mbps output
SMD (Advanced Motion Detection)	Advanced motion detection based on pixel change produced by humans and vehicles reducing false alarms By NVR: Up to 4CH By IP camera with SMD: All channels (Up to 16 targets/second)
IVS Perimeter Protection	Intelligent algorithm based on human and vehicle detection with high precision filtering out any non-interest objects in the environment such as rain, leaves, bright lights, etc. IVS is based on line crossing, intrusion in area, entry region, ... By NVR: Up to 2CH (Up to 10 IVS rules) By IP camera with IVS: All channels (8 targets/second)
Facial Detection	Detection of facial attributes such as: Gender, age group, glasses, expressions, mask or beard By the NVR: Up to 1CH (Up to 12 images/second per channel) By IP camera with Facial Detection: All channels (Up to 8 targets/second)
Facial Recognition	Up to 10 face databases with 20,000 images (2.5G) By NVR: - Up to 8CH using facial detection cameras - Up to 1CH using the NVR itself By IP camera with facial recognition: All channels
QuickPick	Quick search for human and vehicle targets on live video or recording based on SMD detections
Intelligent Event Searches	SMD, IVS, Facial Detection, Facial Recognition, ANPR, People Counting, Heat Map
Simultaneous Multifunction	Pentaplex: Live, Recording, Playback, Backup and Remote Access
Alarms	4 Inputs / 2 Outputs NO/NC
Audio	1 RCA input / 1 RCA output
Recording Method	Manual, scheduled, motion detection, alarm
Backup	USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA
Internal Storage	8 SATA 3.5" HDDs up to 16TB (not included)
Communication	2x USB (Mouse and backup) / 1xRS232 / 1 RJ45 10/100/1000M (Ethernet)
Rackmountable	1U
Remote Access	Browser (ActiveX), Mobile phone application, DSS or DSS PRO software
Power	AC 100~240 V, 50/60 Hz, >10W
Operating Temperature	–10 °C to +55 °C, 10%-93% (RH, non-condensing)
Dimensions	53 (H) x 375 (W) x 329.3 (D) mm / 2.6 Kg
