| Brand | X-SECURITY |
| IP Camera Inputs | LAN Port up to 16 channels |
| Video Outputs | 1 HDMI 4K, 1 VGA |
| Bidirectional Audio | 1 input, 1 output, RCA |
| Video Compression Format | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Decoding Capacity | AI Disabled: 2 channels 16 MP@30 fps; 2 channels 12 MP@30 fps; 4 channels 8 MP@30 fps; 6 channels 5 MP@30 fps; 8 channels 4 MP@30 fps; 16 channels 1080p@30 fps AI Enabled: 1 channel 16 MP@30 fps; 2 channels 12 MP@30 fps; 3 channels 8 MP@30 fps; 4 channels 5 MP@30 fps; 6 channels 4 MP@30 fps; 12p@1080 fps 30 channels |
| Total Bandwidth | AI Disabled: 256 Mbps incoming, 256 Mbps recording, and 256 Mbps outgoing AI Enabled: 180 Mbps incoming, 180 Mbps recording, and 180 Mbps outgoing |
| Recording Resolution | 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 960p, 720p, D1, CIF |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | 4 Inputs / 2 Relay NO/NC |
| SMD Plus | SMD Plus per recorder up to 4 channels: Secondary filtering for human and motorized vehicles, reducing false alarms caused by leaves, rain, and changing lighting conditions. SMD Plus per camera up to 8 channels. |
| Perimeter Protection | Per recorder up to 2 channels, 10 IVS rules for each channel. Per camera up to 8 channels. |
| Face Detection | Per recorder 1 channel (up to 12 facial images per channel) Per camera up to 8 channels. Gender; age group; glasses; Expressions; Mask; beard |
| Facial Recognition | Up to 10 facial databases with 200,00 images, with a total capacity of 2.5 G. Name, gender, date of birth, address, credential type, credential number, countries and regions, and status can be added to each face image. |
| AI Facial Recognition Performance per Camera (number of channels) | 8 channels |
| AI Facial Recognition Performance per Recorder (number of channels) | FD of 8 channels (per camera) + FR (per recorder), image flow: 12 face images/s FD of 1 channel (per recorder) + FR (per recorder), video flow: 12 face images/s |
| Internal Storage | 2 HDD SATA 3.5" up to 16 TB (not included) |
| Alarms | 4 input relays / 2 output relays |
| Communication | 2xUSB / 1 RJ45 10/100/1000M (Ethernet) / 16 ports, 10/100 Mbps, IEEE 802.3 af-at |
| Remote Access | Browser (ActiveX), Mobile phone application, or Smart PSS software |
| Power | 100–240 VAC, 47-63 Hz |
| Dimensions | 53 (H) x 329.3 (W) x 375 (D) mm / 2.6 Kg (without HDD) |
