| Brand | X-SECURITY |
| IP Camera Inputs | LAN Port up to 16 channels |
| Compatible IP Cameras | X-SECURITY (proprietary protocol), ONVIF |
| Video Outputs | 1 HDMI 4K, 1 VGA |
| Bidirectional Audio | 1 input, 1 output, RCA |
| Video Compression Format | Smart H.265+ / H.265 / Smart H.264+ / H.264 |
| Display Resolution | 3840×2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Total Bandwidth | 384 Mbps |
| Recording Resolution | 12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P ... |
| Simultaneous Multifunction | Pentaplex: Live, Recording, Playback, Backup, and Remote Access |
| Alarms | 4 Inputs / 2 Relay NO/NC |
| Recording Method | Manual, scheduled, motion detection, alarm |
| Artificial Intelligence | Facial recognition up to 2Ch, perimeter protection up to 4Ch, and SDD plus up to 8CH |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network / SATA |
| Internal Storage | 2 HDD SATA 3.5" up to 10 TB (not included) |
| Communication | 3xUSB (Mouse and backup) / 1 RJ45 10/100/1000M (Ethernet) |
| Remote Access | Browser (ActiveX), Mobile phone application, or PSS software |
| Power Supply | AC 100~240V 50~60 Hz |
| Dimensions | 53 (H) x 329 (W) x 375 (D) mm / 1.57 Kg (without HDD) |
Data sheet
