DS-KV8113-WME1(C) | |
| Brand | Hikvision |
| Model | DS-KV8113-WME1(C) |
| Operating System | Linux |
| Image Sensor | 1/3" 2 MP CMOS wide-angle IR |
| Image Functions | BLC / WDR / DNR |
| Viewing Angle | H: 124º, V: 75º |
| Audio | Two-way audio with microphone and speaker |
| Access Control | Door opening with MF card 13.56 MHz Up to 2,000 users and 10,000 cards |
| Keyboard | Mechanical call button with LED customization label |
| Outputs | 2 x relay for lock, 1 x RS485 |
| Inputs | 4 x auxiliary inputs (exit button, feedback, door sensor), 1 x tamper |
| Remote Access | Web browser iVMS-4200 software Hik-Connect mobile app |
| Network Interface | Ethernet 10/100 BaseT / SIP 2.0 Protocol / WiFi (only for app connection via P2P) |
| Power Supply | DC 12 V / 1000 mA max. / PoE IEEE802.3af |
| Protection Rating | Outdoor suitable IP65 Vandal-resistant IK08 |
| Material | Aluminum alloy |
| Operating Temperature | -40 ºC ~ +55 ºC |
| Dimensions | 174 (H) x 91 (W) x 29 (D) mm |
| Weight | 380 g |
DS-KH6320-WTE1 | |
| Brand | Hikvision |
| Model | DS-KH6320-WTE1 |
| Operating System | Linux |
| Screen Type | 7" color touch TFT |
| Screen Resolution | 1024 x 600 |
| Inputs | 8 x configurable alarms, 1 x RS485 |
| Outputs | 2 x relay |
| Audio | Two-way audio with built-in microphone and speaker Noise reduction and echo cancellation |
| Memory | MicroSD card slot (up to 128 GB) |
| Connection | Ethernet 10/100 BaseT / RTSP / SIP 2.0 Protocol / WiFi 802.11 b/g/n (only for app connection via P2P) |
| Remote Access | iVMS-4200 software Hik-Connect mobile app |
| Power Supply | DC 12 V / 1 A max. / PoE IEEE802.3af |
| Operating Temperature | -10 ºC ~ +55 ºC |
| Dimensions | 140 (H) x 200 (W) x 15 (D) mm |
| Weight | 355 g |
| Slave Monitors | Android monitors DS-KH9310 and DS-KH9510 cannot be used as slaves |
