DS-KAD7060EY | |
| Brand | Hikvision |
| Model | DS-KAD7060EY |
| Operation Mode | Power, video, and audio via HD 2-wire technology |
| Outputs | 2 HD 2-wire channels with a maximum power of 15 W each 4 HD 2-wire channels with a maximum power of 110 W among the four |
| Cascading | 2 channels for cascading connection of DS-KAD7060EY |
| Capacity | Can power up to 22 WiFi monitors (DS-KH7300EY-WTE2) or 64 non-WiFi monitors (DS-KH7300EY-TE2) Can power up to 16 mini distributors DS-KAD7061EY or DS-KAD7062EY |
| Communication | HD 2-wire technology (up to 6 devices) |
| Power Supply | DC 48 V / 3.2 A max. |
| Operating Temperature | -10º C ~ +55º C |
| Dimensions | 144 (W) x 92 (H) x 66 (D) mm |
| Weight | 250 g |
DS-KH7300EY-WTE2/White | |
| Brand | Hikvision |
| Model | DS-KH7300EY-WTE2/White |
| Operating System | Linux |
| LCD | 7" color touch TFT |
| Screen Resolution | 1024 x 600 |
| Operation Mode | Additional touch button panel: call initiation, call termination, and door opening LED status indicators |
| Inputs | 1 x HD 2-wire, 1 x handheld headset |
| Outputs | 1 x HD 2-wire |
| Audio | Two-way audio with built-in microphone and speaker Noise reduction and echo cancellation |
| Memory | MicroSD card slot (up to 128 GB) |
| Connection | HD 2-wire / RTSP / WiFi 802.11b/g/n (only for app connection via P2P) |
| Remote Access | Hik-Connect mobile application |
| Power Supply | Via specific Hikvision hub for HD 2-wire intercoms (4 W max.) |
| Operating Temperature | -10 ºC ~ +50 ºC |
| Dimensions | 138 (H) x 190 (W) x 20 (D) mm |
| Weight | 350 g |
| Color | White |
| Slave Monitors | Monitors not belonging to the HD 2-wire system cannot be used |
DS-KAW150-4N | |
| Brand | Hikvision |
| Model | DS-KAW150-4N |
| Power Input | AC 100~240 V / 1.8 A / 50/60 Hz |
| Power Output | DC 48 V / 3.2 A |
| Voltage Range | Adjustable 43.2~55.2 V |
| Maximum Output Power | 150 W |
| Number of Outputs | 2 |
| Operating Temperature | -10º C ~ +70º C |
| Dimensions | 178 (W) x 97 (H) x 38 (D) mm |
| Weight | 540 g |
DS-KV7413EY-IME2-1 | |
| Brand | Hikvision |
| Model | DS-KV7413EY-IME2-1 |
| Operating System | Linux |
| Image Sensor | Low Illumination 2 MP IR |
| Image Functions | BLC / WDR / DNR |
| Field of View | H: 135º, V: 85º |
| Audio | Two-way audio with microphone and speaker |
| Access Control | Door opening with MF 13.56 MHz card Up to 2,000 users and 10,000 cards |
| Keyboard | Mechanical call button with LED customization label |
| Outputs | 2 x relay for lock (1 with DC 12 V / 300 mA), 1 x RS485 |
| Inputs | 2 x auxiliary inputs (exit button, door sensor), 1 x tamper |
| Remote Access | Hik-Connect mobile application AP WiFi mode for configuration |
| Network Interface | Network connection via HD 2-wire |
| Power Supply | DC 48 V with HD 2-wire hub DS-KAD7060EY / 12 V / 1700 mA max. |
| Protection Rating | Outdoor suitable IP65 Vandal-proof IK08 |
| Material | Plastic and stainless steel |
| Operating Temperature | -40 ºC ~ +60 ºC |
| Dimensions | 165 (H) x 95 (W) x 25 (D) mm |
| Weight | 400 g |
