| Brand | Hikvision |
| Range | VALUE |
| Image Sensor | High Performance CMOS |
| Maximum resolution | 1080p (1920x1080) at 30 fps |
| Resolution | TVI: 1080p (25~30 fps) CVI: 1080p (25~30 fps) AHD: 1080p (25~30 fps) CVBS: PAL/NTSC |
| Lens | 3.6 mm |
| Angle of view (FOV) | 78º (H), 42º (V), 92º (D) |
| Minimum illumination | 0.01 Lux @ (F1.6, AGC ON) 0 lux with IR range 30 m |
| Illumination supplementary | Hybrid light; IR range 30 m White light range 20 m |
| Day / Night | Auto / Color / Black and white (ICR) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Via Switch |
| Functions basic | OSD menu (remote) |
| Configurable OSD functions | DWDR, BLC, HLC, AGC, AWB, Smart IR |
| Communication | HIKVISION-C |
| Audio | Integrated microphone Audio via coaxial cable in TVI technology |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 3.3 W max. |
| Degree of protection | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 85.1 mm x 80 mm (H) |
| Base diameter | Ø base 85.1 mm / Ø between screws 60 mm / 3 screws |
| Weight | 296 g |
