| Brand | Hikvision | |
| Range | Value | |
| Image Sensor | High Performance CMOS Ultra Low Light | |
| Maximum resolution | 1080p (1920x1080) at 30 fps | |
| Resolution | TVI: 1080p (25~30 fps) CVI: 1080p (25~30 fps) AHD: 1080p (25~30 fps) CVBS: PAL/NTSC | |
| Lens | 2.8 mm | |
| Angle of view (FOV) | 106º (H) | |
| Minimum Illumination | 0.005 Lux @ (F1.2, AGC ON) | |
| Infrared Illumination | 0 Lux / (EXIR 2.0 IR range 30 m) | |
| Day / Night | Auto / Color / Black and White (ICR) | |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS | |
| Video output switching | Using Switch | |
| Basic functions | OSD menu (remote) | |
| Configurable OSD functions | WDR (120 dB), BLC, HLC, 3DNR, AGC, AWB, AE, Mirror function, Smart IR | |
| Communication | HIKVISION-C | |
| Lens Positioning | 3 Axis | |
| Power | DC 12 V / 4.6 W max. | |
| Protection grade | Waterproof IP67 | |
| Temp. operation | -40º C ~ +60º C | |
| Material | Metal | |
| Dimensions | 68.2 mm (H) x 82.6 mm (w) >Weight | 240 g |
Data sheet
