- Hikvision Managed HiPoE Switch
- 4 PoE 802.3af/at ports + 2 Uplink RJ45
- 4 RJ45 10/100Mbps + 2 RJ45 10/100Mbps
- 802.3af/at/bt / Maximum 60W
- VLAN/Port Isolation/Loop Detection/LLDP
- Link Aggregation/PoE Watchdog/SNMP
Description & Key Features: DS-3E1106HP-EI
The DS-3E1106HP-EI is a managed desktop switch designed for efficient network management and power distribution. Ideal for small to medium-sized businesses, this device features 4 PoE+ ports and 2 uplink ports, making it perfect for connecting IP cameras and other network devices. With a total power supply of up to 60W for all ports, it supports PoE standards including IEEE802.3af/at/bt, ensuring compatibility with a wide range of devices. The switch can be easily managed using Hik-Partner Pro and Hik-Central Pro, providing a powerful and intuitive interface for users.
- Hikvision
- Managed HiPoE Desktop Switch
- 4 PoE+ RJ45 10/100Mbps + 2 Uplink 10/100Mbps
- Supports PoE power up to 60W total for all ports
- Compatible with PoE IEEE802.3af/at/bt
- Powerful and intuitive management with Hik-Partner Pro and Hik-Central Pro
Specifications: DS-3E1106HP-EI
| Brand | Hikvision |
| Interface | 4 PoE+ RJ45 10/100 Mbps + 2 RJ45 10/100 Mbps uplink |
| RJ45 Port Speed | 6x 10/100Mbps |
| PoE Power Supply | Hi-PoE port 1 PoE/PoE+ 802.3af/at port 2-4 Up to 60W total power |
| Extended PoE | Up to 300 meters (this may vary depending on the camera model or cable condition) |
| Management Protocols | Web/Hik-Partner Pro/Hik-Central Pro |
| Technologies and Protocols | Loop Detection (STP and RSTP) Up to 32 VLANs (supports trunk and access mode) Port Isolation Link Aggregation (supports static link aggregation) Supports an aggregation group PoE Watchdog LLDP/HPP SNMP v1/v2c Management IP 10.180.190.200 |
| Power Supply | External power adapter 48V/1.35A |
| Operating Temperature | 0° C ~ 40° C |
| Dimensions | 68.45 (L) x 25.6 (H) x 145 (W) mm |
| Weight | 0.645 kg (with package) |
Package Contents
- Switch
- External power adapter 48V/1.35A
- User manual
Use Case
The DS-3E1106HP-EI switch is an excellent choice for installers looking to set up a reliable network for surveillance systems in office environments. For instance, in a medium-sized office, the switch can connect multiple IP cameras and other devices, ensuring seamless data transmission. With its PoE capabilities, the switch eliminates the need for additional power sources, simplifying installation and reducing clutter. The extended PoE feature allows for camera placements up to 300 meters away, providing flexibility in positioning. Additionally, the management protocols such as Hik-Partner Pro enable remote monitoring and configuration, making it easier for IT staff to maintain the network. Overall, the DS-3E1106HP-EI enhances network efficiency while supporting a robust security infrastructure.
