NVR recorder for A2 range IP cameras SF-NVR8432A-B2

NVR recorder for A2 range IP cameras SF-NVR8432A-B2

Name: NVR recorder for A2 range IP cameras SF-NVR8432A-B2
Brand: SAFIRE SMART
Price: 502.479339 EUR
Availability: InStock

Brand: SAFIRE SMART

SKU: SF-NVR8432A-B2

Condition: New product

Safire Smart
NVR recorder for A2 range IP cameras
32CH video / H.265+ / 4HDD
Resolution up to 12Mpx / Bandwidth 320Mbps
HDMI 4K, HDMI FullHD and VGA / Dewarping Fisheye
Facial recognition / Smart searches

More details

Rating: Sign in to write a review

Overview
Data sheet
Reviews (0)

Overview

NVR recorder for IP cameras A2 range SF-NVR8432A-B2

Safire Smart
B2 range - NVR recorder for IP cameras
32 CH
Supported bandwidth 320Mbps
Maximum resolution 12 Megapixel
Compression H.265+/H.265/H.264+/H.264
1 4K HDMI output, 1 FullHD HDMI output and 1 VGA output
POS function
Face recognition
Face tracking on map
Dewarping for Fisheye cameras
Dual Stream IP access
Mouse
RCA Audio
Alarms
Space for 4 10TB HDDs
Power ≤150W
WEB, CMS and Smartphone interface
ONVIF compatible

Technical specifications

Brand	Safire Smart
Range	B2
Camera inputs IP	32 CH IP
Supported IP cameras	Safire Smart (native protocol), ONVIF
Two-way audio	1 input / 1 RCA output
Main Stream Recording	12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF
Decoding capacity	1CH 12Mpx @ 20FPS 4CH 1080P @ 30FPS
Video compression format	H.265+ / H.265 / H.264+ / H.264
Audio compression	G.711(U/A)
Bandwidth total	320 Mbps input / 256 Mbps output
Video outputs	1 HDMI 4K / 1 HDMI 1080p / 1 VGA
Display resolution	HDMI 1: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768 HDMI 2: 1920x1080, 1280x1024, 1024x768 VGA: 1920x1080, 1280x1024, 1024x768 VGA and HDMI 1 are simultaneous HDMI 1 and HDMI 2 independent
Simultaneous multifunction	Pentaplex: Direct, Recording, Playback, Backup and Remote Access
Multi-Screen	Main Output: 1 / 4 / 6 / 8 / 9 / 13 / 16 / 25 / 32 / 36 (Live View) AUX Output: 1 / 4 / 6 / 8 / 9 (Live View) Max. 32+9CH local (Live View)
Recording method	Manual, scheduled, motion detection, smart events, alarm input, POS
POS function	Yes
Perimeter Protection	Need to use Safire Smart cameras with artificial intelligence Artificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on: - Area intrusion - Line crossing - Region entry - Region exit region Detailed searches for smart events
Face Detection	Face recognition up to 6CH Computing up to 18 images / second 32 Libraries and up to 10,000 face images
Video metadata	Feature extraction of humans and vehicles For humans: possibility of extracting up to 13 characteristics (glasses, color of clothing, etc.) For vehicles: possibility of extracting up to 5 characteristics (color, type, etc.)
License plate recognition	Yes (Safire Smart license plate camera required)
Dewarping	Supports Fisheye camera dewarping
Alarms	16 Inputs / 4 Outputs
External backup	USB memory / USB HDD / USB CD-RW / USB DVR-RW
Internal storage	4 x 3.5" SATA3.0 HDD up to 10 TB each (not included)
Communication	1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485
Remote Access	Web Browser, Safire Smart Smartphone App and Safire Smart VMS PC Software
Power	ATX 300W(PoE)
Operating temperature	-10ºC ~ 50ºC, Humidity 10~90%
Dimensions / Weight	70 (H) x 440 (W) x 390 (Fo) mm / 4.44 Kg
