Name: NVR recorder for B2 range IP cameras SF-NVR8832A-16P-B2
Brand: SAFIRE SMART
Price: 710.743802 EUR
Availability: InStock

Brand: SAFIRE SMART

SKU: SF-NVR8832A-16P-B2

Condition: New product

Safire Smart
NVR recorder for B2 range IP cameras
32CH (16 PoE Ports) / H.265S Compression / 8HDD
Resolution up to 12Mpx / Bandwidth 192Mbps
HDMI 4K, HDMI FullHD and VGA / Dewarping Fisheye
Facial Recognition, Data Metadata video

More details

Rating: Sign in to write a review

Overview
Data sheet
Reviews (0)

Overview

NVR recorder for IP cameras B2 range SF-NVR8832A-16P-B2

Safire Smart
B2 range
NVR recorder for IP cameras
32 CH
16 PoE Ports 802.3af/at
Bandwidth supported 192 Mbps
Maximum resolution 12 Megapixel
H.265S/H.265+/H.265/H.264+ compression
1 4K HDMI output, 1 FullHD HDMI and 1 VGA output
POS function
Smart searches for humans, vehicles and two-wheelers
Facial recognition
Tracking face on map
Dewarping for Fisheye cameras
Arming / Disarming from the mobile APP
Dual Stream IP access
RCA Audio
Alarms
Space for 8 HDD
Power ≤150W
WEB, CMS and Smartphone interface
Compatible with ONVIF
NDAA Certified

Technical specifications

Brand	Safire Smart
Range	B2
Inputs for IP cameras	32CH IP
PoE Ports	16xRJ45 10/100M Power ≤150W, PoE 802.3af/at
Compatible IP cameras	Safire Smart (native protocol), ONVIF
Two-way audio	1 input / 1 RCA output
Main Stream Recording	12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF
Decoding Capability	1CH 12Mpx @ 20FPS 4CH 1080P @ 30FPS
Video compression format	H.265S / H.265+ / H.265 / H.264+
Audio compression	G.711(U/A)
Total bandwidth	192 Mbps in / 192 Mbps out
Outputs video	1 HDMI 4K / 1 HDMI FullHD / 1 VGA
Display resolution	HDMI 1: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768 HDMI 2: 1920x1080, 1280x1024, 1024x768 VGA: 1920x1080, 1280x1024, 1024x768 HDMI 1 and HDMI 2 independent HDMI 1 and VGA simultaneous
Simultaneous multifunction	Pentaplex: Live, Recording, Playback, Backup and Remote Access
Multi-Screen	Output Main: 1 / 4 / 6 / 8 / 9 / 13 / 16 (Live View) Sub Output: 1 / 4 / 6 / 8 / 9 (Live View) AI Mode (Default): Max. 16CH (simultaneous HDMI and VGA) AI in recorder available Independent video output: Max. 25CH (HDMI and VGA independent) AI per recorder not available
Recording method	Manual, scheduled, motion detection, smart events, alarm input, POS
Function POS	Yes
Perimeter Protection	Necessary to use Safire Smart cameras with artificial intelligence Artificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on: - Intrusion in area - Line crossing - Entry of region - Region output Detailed searches for smart events
Facial recognition	Face detection with Safire Smart 4I1 or 8I2 cameras up to 16CH (All channels) Facial detection by the NVR itself with any camera up to 2CH Facial recognition up to 6CH maximum Computation of up to 18 images / second 32 Libraries and up to 10,000 face images Searches by image through the recorder, APP and PC software Face tracking on a map or plane Statistical information on face results by day, week, month or personalized period
Video metadata	Required to use Safire Smart 4I1 or 8I2 cameras Extraction of features from humans and vehicles For humans: possibility of extracting up to 13 characteristics (glasses, color of clothing, etc.) For vehicles: possibility of extracting up to 5 characteristics (color, type, etc.)
License plate recognition	Yes (Safire Smart license plate camera required)
Dewarping	Supports camera dewarping Fisheye
Alarms	16 Inputs / 4 Outputs
External backup	USB memory / USB HDD / USB CD-RW / DVR-RW USB
Internal storage	8x HDD 3.5" SATA3.0 up to 10 TB (not included)
e-SATA interface	1 x e-SATA
Communication	1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485
Remote Access	Web Browser, Safire Smart Smartphone App and Safire Smart VMS PC Software
Power	ATX300W ≤ 30W (No hard drive)
Operating temperature	-10ºC ~50ºC, Humidity 10~90%
Dimensions / Weight	90 (H) x 445 (W) x 436 (Fo) mm / 1.18 Kg
