NVR recorder for B2 range IP cameras SF-NVR8232A-B2
Brand: SAFIRE SMART
- Safire Smart
- NVR recorder for B2 range IP cameras
- 32CH video / H.265S Compression / 2HDD
- Resolution up to 12Mpx / Bandwidth 192Mbps
- 2 HDMI and VGA / Fisheye Dewarping
- Facial recognition, Video metadata
NVR recorder for B2 range IP cameras SF-NVR8232A-B2
- Safire Smart
- B2 range
- NVR recorder for IP cameras
- 32 CH
- Supported bandwidth 192 Mbps
- Maximum resolution 12 Megapixel
- H.265S/H.265+/H.265/H.264+ compression
- 1 4K HDMI output, FullHD HDMI output and 1 VGA output
- POS function
- Smart searches for humans, vehicles and two-wheelers
- Face recognition
- Face tracking on map
- Dewarping for cameras Fisheye
- Arming / Disarming from the mobile APP
- Dual Stream IP access
- RCA Audio
- Alarms
- Space for 2 HDD
- WEB, CMS and Smartphone interface
- ONVIF compatible
- NDAA certified
Technical specifications
| Brand | Safire Smart | |
| Range | B2 | |
| IP camera inputs | 32CH IP | |
| Supported IP cameras | Safire Smart (native protocol), ONVIF | |
| Two-way audio | 1 input / 1 RCA output | |
| Main Stream Recording | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF | |
| Decoding Capability | 1CH 12Mpx @ 20FPS 4CH 1080P @ 30FPS >Audio compression | G.711(U/A) |
| Total bandwidth | 192 Mbps in / 192 Mbps out | |
| Outputs video | 1 HDMI 4K / 1 HDMI FullHD / 1 VGA | |
| Display resolution | HDMI 1: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768 HDMI 2: 1920x1080, 1280x1024, 1024x768 VGA: 1920x1080, 1280x1024, 1024x768 *HDMI 1 and HDMI 2 independent *HDMI 1 and VGA simultaneous | |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access | |
| Multi-Screen | Output Main: 1 / 4 / 6 / 8 / 9 / 13 / 16 / 25 / 36 (Live View) movement, smart events, alarm input, POS | |
| POS function | Yes | |
| Perimeter Protection | Necessary to use Safire Smart cameras with artificial intelligence Artificial Intelligence based on classification of humans, vehicles and two-wheelers on: - Area intrusion - Line crossing - Region entry - Region exit Detailed searches for smart events | |
| Face Recognition | Face Detection with Safire Smart Cameras 4I1 or 8I2 up to 32CH (All channels) Face detection by the NVR itself with any camera up to 2CH Facial recognition up to 6CH maximum Computation of up to 18 images / second 32 Libraries and up to 10,000 images of faces Searches by image through the recorder, APP and software PC Face tracking on map or plane Statistical information on face results by day, week, month or custom period | |
| Video metadata | Necessary to use Safire Smart 4I1 or 8I2 cameras Extraction of features of humans and vehicles For humans: possibility of extract up to 13 characteristics (glasses, color of clothing, etc.) For vehicles: possibility of extracting up to 5 characteristics (color, type, etc.) | |
| License plate recognition | Yes (Safire Smart license plate camera required) | |
| Dewarping | Supports dewarping of Fisheye cameras via web and APP | |
| Alarms | 16 Inputs / 4 Outputs | |
| External backup | USB memory / USB HDD / USB CD-RW / USB DVR-RW | |
| Internal storage | 2x 3.5" SATA3.0 HDD up to 10 TB (not included) | |
| Communication | 1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485 | |
| Access remote | Web Browser, Safire Smart Smartphone App and Safire Smart VMS PC Software | |
| Power | DC 12V / 4A, ≤ 20W (Without hard drive) | |
| Operating temperature | -10ºC ~50ºC, Humidity 10~90% | |
| Dimensions / Weight | 48.1 (H) x 380 (W) x 268 (Fo) mm / 1.18 Kg |
Contents
- Safire Smart B2 NVR Recorder
- Mouse
- Ethernet Cable
- 12V DC Power Supply
- Quick Guide
