NVR recorder for B2 range IP cameras SF-NVR8432A-16P-B2
Brand: SAFIRE SMART
- Safire Smart
- NVR recorder for B2 range IP cameras
- 32CH video / PoE 16CH / H.265+ / 4HDD
- Resolution up to 12Mpx / Bandwidth 320Mbps
- Facial recognition / Smart search
- HDMI 4K, HDMI FullHD and VGA / Dewarping Fisheye
NVR recorder for IP cameras B2 range SF-NVR8432A-16P-B2
- Safire Smart
- B2 range - NVR recorder for IP cameras
- 32 CH
- Switch 16 PoE ports 150 W
- Supported bandwidth 320Mbps
- Maximum resolution 12 Megapixel
- H.265+/H.265/H.264+/H.264 compression
- 1 4K HDMI output, 1 FullHD HDMI output and 1 VGA output
- POS function
- Face recognition
- Face tracking on map
- Dewarping for cameras Fisheye
- Dual Stream IP Access
- Mouse
- RCA Audio
- Alarms
- Space for 4 10TB HDDs
- Power ≤150W
- WEB, CMS and Smartphone interface
- ONVIF compatible
Technical specifications
| Brand | Safire Smart |
| Range | B2 |
| Inputs for IP cameras | 32CH IP |
| PoE ports | 16 RJ45 10/100M Power ≤150W, PoE 802.3af/at |
| IP cameras supported | Safire Smart (native protocol), ONVIF |
| Two-way audio | 1 input / 1 output RCA |
| Main Stream Recording | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF |
| Decoding capacity | 1CH 12Mpx @ 20FPS 4CH 1080P @ 30FPS |
| Video compression format | H.265+ / H.265 / H.264+ / H.264 |
| Audio compression | G.711(U/A) |
| Total bandwidth | 320 Mbps input / 256 Mbps output |
| Video outputs | 1 HDMI 4K, 1 HDMI 1080p, 1 VGA |
| Display resolution | HDMI 1: 3840x2160@30FPS, 1920x1080, 1280x1024, 1024x768 HDMI 2: 1920x1080, 1280x1024, 1024x768 1280x1024, 1024x768 *VGA and HDMI 1 are simultaneous *HDMI 1 and HDMI 2 independent |
| Simultaneous multifunction | Pentaplex: Direct, Recording, Playback, Backup and Access Remote |
| Multi-Screen | Main Output: 1 / 4 / 6 / 8 / 9 13 / 16 / 25 / 32 / 36 (Live View) AUX Output: 1 / 4 / 6 / 8 / 9 (Live View) live) Max: 32+9CH Local (Live View) |
| Recording method | Manual, scheduled, motion detection, smart events, alarm input, POS |
| Function POS | Yes |
| Perimeter Protection | Necessary to use Safire Smart cameras with artificial intelligence Artificial Intelligence based on the classification of humans, vehicles and two-wheeled vehicles on: - Intrusion in area - Line crossing - Entry of region - Region output Detailed searches for smart events |
| Smart functions | Searches by image through the recorder, APP and software Searches for TrueSense smart events by human and vehicle (Required camera with TrueSense). |
| Face Detection | Up to 2CH by the recorder itself Face detection with Safire Smart 4I1 or 8I2 cameras up to 32CH (All channels) Chart of facial detection statistics by day, week, month, year. |
| Video metadata | Up to 2CH by the recorder itself For classification and extraction of attributes it is necessary to use Safire Smart 4I1 or 8I2 cameras, in order to obtain: For humans: possibility of extracting up to 13 characteristics (glasses, color of clothing, etc.) For vehicles: possibility of extracting up to 5 characteristics (color, type, etc.) |
| Facial Recognition | Facial recognition up to 6CH Computation of up to 18 images / second 32 Libraries and up to 10,000 images faces |
| Dewarping | Supports dewarping of Fisheye cameras |
| Alarms | 16 Inputs / 4 Outputs |
| External backup | USB memory / USB HDD / USB CD-RW / USB DVR-RW |
| Internal storage | 4 x 3.5" SATA3.0 HDDs up to 10 TB each (not included) |
| Communication | 1 x USB 3.0 / 2 x USB 2.0 / 2 x RJ45 10/100/1000M (Ethernet) / RS485 |
| Remote Access | Web Browser, Safire Smart Smartphone App and Safire Smart VMS PC Software |
| Power | ATX 300W(PoE) |
| Operating temperature | -10ºC ~ 50ºC, Humidity 10~90% |
| Dimensions / Weight | 70 (H) x 440 (W) x 390 (Fo) mm / 4.44 Kg |
Contents
- Safire Smart NVR Recorder
- Mouse
- Ethernet cable
- Power cable
- Quick guide
