| Brand | Hikvision |
| Range | Value |
| Image Sensor | 3K CMOS |
| Maximum resolution | 3K (2960x1665) at 20 fps |
| Resolution | TVI: 3K (20 fps), 4 Mpx (25~30 fps), 1080p (25~30 fps) CVI: 4Mpx (25~30 fps) AHD: 5Mpx (30 fps), 4 Mpx (25~30 fps) CVBS: PAL/NTSC |
| Lens | 2.8 mm |
| Viewing angle (FOV) | 107º (H), 64º (V), 129º (D) |
| Minimum illumination | Color: 0.01 Lux @ (F1.2, AGC ON) Black and white: 0 lux with IR |
| Infrared lighting | Dual light: Smart IR range 20 m White light range 20 m |
| Day / Night | Auto / Color / Black and White (ICR) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Switching video output video | Via Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, AGC, AWB, Smart IR |
| Audio | Integrated microphone (audio via coaxial cable in TVI technology) |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 2.9 W max |
| Protection degree | Suitable for indoors |
| Temp. operation | -40º C ~ +60º C |
| Material | Plastic |
| Dimensions | Ø 85.02 mm x 84.6 mm (Al) |
| Base diameter | Ø base 85.02 mm / Ø between screws 60 mm / 3 screws |
| Weight | 160 g |
