| Brand | Safire Smart |
| Range | E1 |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 4 Megapixel (2560x1440) |
| Minimum illumination | Color: 0.005 Lux @(F1.6, AGC ON), 0 Lux with IR |
| IR range | 30 m |
| Day/night | Removable ICR mechanical filter |
| Electronic Shutter | 1/2~1/100,000 s |
| Main Stream Rate | 25 FPS (4Mpx, 3Mpx, 1080P, 720P) |
| Extra Stream Rate | 25 FPS (720P, D1, CIF) |
| Third Stream Rate | 25 FPS (D1, 480x240, CIF) |
| Compression | H.265 / H.264 |
| Bitrate | 64 Kbps ~ 8 Mbps |
| Optics | 2.8 mm |
| Angle of view (FOV) | H: 94°, V: 50°, D: 115° |
| DORI | 62 m (R), 25 m (W), 12 m (R), 6 m (L) |
| Image improvements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI |
| Motion Detection | Yes |
| Functions Intelligent | Artificial intelligence based on human and vehicle classification on: Area intrusion, Line crossing, entry region, exit region Other intelligent events: abandoned object, removed object, Video exceptions (scene change, video loss, ...) |
| Audio | 1 Input |
| Audio compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal storage | microSD card up to 256GB |
| Remote access | Web Browser, Safire Smart Smartphone App, Safire Smart VMS PC Software |
| WiFi | IEEE802.11 b/g/n Frequency: 2.4 ~2.4835 GHz Channel Bandwidth: 20MHz Security: WEP, WPA-PSK/WPA2-PSK Open field range: 80m Transfer: 11b (11Mbps), 11g (54Mbps) and 11n (up to 150Mbps) |
| Interoperability | ONVIF |
| P2P | Yes |
| Power | DC 12 V / 666 mA / 5 W max. / PoE IEEE802.3af |
| Protection grade | Waterproof IP67 |
| Material | Metal and plastic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 148.2 (H with antenna) x 74.50 (W) x 167.5 (Fo) mm |
| Weight | 660 g |
