| Brand | Safire Smart | ||
| Range | E1 | ||
| Image Sensor | 1/2.5" Progressive Scan CMOS | ||
| Maximum resolution | 6 Megapixel (3200×1800) | ||
| Minimum Illumination | Color: 0.008 Lux @(F1.6, AGC ON), 0 Lux with IR | ||
| Dual Light Range | IR: 50 m White Light: 40 m | ||
| Day/night | Removable ICR mechanical filter | ||
| Electronic Shutter | 1/2~1/100,000 s | ||
| Main Stream Rate | 20 FPS (6Mpx) 30 FPS (4Mpx, 1080P) | ||
| Extra Stream Rate | 25 FPS (720P, D1, CIF) | ||
| Third Stream Rate | 25 FPS (D1, 480x240, CIF) | ||
| Compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG | ||
| Bitrate | 64 Kbps ~ 8 Mbps | ||
| Optics | 3.6 mm | ||
| Angle of view (FOV) | H: 78°, V: 38°, D: 94° | ||
| DORI | 105 m (R), 42 m (W), 21 m (R), 10 m (L) | ||
| Image enhancements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI | ||
| Motion Detection | Yes | ||
| Smart Features | Artificial intelligence based on human and vehicle classification on: Intrusion Area, Line Crossing, Entry Region, Exit Region class="table-data"> | Audio compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT | ||
| Internal storage | MicroSD card up to 256GB | ||
| Remote access | Web browser, Safire Smart Smartphone App, Safire Smart VMS PC Software | ||
| Interoperability | ONVIF | ||
| Power | DC 12 V / 9.5 W max. / PoE IEEE802.3af | ||
| Protection grade | Waterproof IP67 | ||
| Material | Metal and plastic | ||
| Temp. operation | -30º C ~ +60º C | ||
| Dimensions | 80.5 (H) x 80.5 (W) x 217.8 (D) mm | ||
| Weight | 680 g |
Data sheet
