| Brand | Safire Smart | |
| Range | E1 | |
| Image Sensor | 1/2.5" Progressive Scan CMOS | |
| Maximum resolution | 6 Megapixel (3200 × 1800) | |
| Minimum illumination | Color: 0.008 Lux @(F1.6, AGC ON), 0 Lux with IR | |
| Dual Light Range | IR: 50 m White Light: 30 m | |
| Day/night | Removable ICR mechanical filter | |
| Electronic Shutter | 1/2~1/100,000 s | |
| Rate Main Stream | 60Hz: 8MP (20fps) / 6MP / 4MP / 2K / 1080P (30fps) >Extra Stream Rate | 720P / D1 / VGA / 640×360 / CIF / 480×240 (60Hz: 30fps; 50Hz: 25fps) |
| Third Stream Rate | 720P / D1 / 640×360 /CIF (60Hz: 30fps; 50Hz: 25fps) | |
| Compression | H.265+ / H.265 / H.264+ / H.264 / MJPEG | |
| Bitrate | 64 Kbps ~ 8 Mbps | |
| Optics | 2.8-12 mm Motorized | |
| Angle of view (FOV) | H: 97.3°~34°, V: 52.3°~17.7°, D: 116°~37° | |
| DORI | 277~88 m (D), 111~35 m (W), 55~17 m (R), 28~8 m (L) | |
| Image Enhancements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI | |
| Motion Detection | Yes | |
| Intelligent Functions | Artificial intelligence based on human and vehicle classification on: Area intrusion, Line crossing, entry region, exit region Other intelligent events: abandoned object, removed object, Video exceptions (scene change, video loss, ...) | |
| Audio | 1 Input / Integrated Microphone | |
| Audio compression | G711A / U | |
| Interface network | Ethernet 10 / 100M BaseT | |
| Internal storage | microSD card up to 256GB | |
| Access remote | Web Browser, Safire Smart Smartphone App, Safire Smart VMS PC Software | |
| Interoperability | ONVIF | |
| Power | DC 12V/12W max / PoE IEEE802.3af | |
| Protection grade | Waterproof IP67 | |
| Material | Metal and plastic | |
| Temp. operation | -30º C ~ +60º C | |
| Dimensions | 80.5 (H) x 80.5 (W) x 217.8 (D) mm | |
| Weight | 680 g |
