| Brand | Safire Smart | ||
| Range | I2 | ||
| Image Sensor | 1/2.8" Progressive Scan CMOS | ||
| Maximum resolution | 8 Megapixel (3840x2160) | ||
| Minimum Illumination | Color: 0.02 Lux @(F1.6, AGC ON), 0 Lux with IR | ||
| IR range | 50 m | ||
| Day/night | Removable ICR mechanical filter | ||
| Electronic Shutter | 1/2~1/100,000 s | ||
| Rate Main Stream | 25 FPS (8Mpx, 6Mpx, 5Mpx, 4Mpx, 2K, 3Mpx, 1080P, 720P) HFR mode: 60 FPS (1080P / 720P) | ||
| Extra Rate Stream | 25 FPS (720P, D1, CIF, VGA, 480x240) | ||
| Third Stream Rate | 25 FPS (720P, D1, 480x240, CIF) | ||
| Compression | H.265+ / H.265 / H.264+ / H.264 | ||
| Bitrate | 64 Kbps ~ 12Mbps | ||
| Optics | 2.8 mm | ||
| Angle of view (FOV) | H: 104°, V: 55°, D: 125° | ||
| DORI | 83 m (R), 33 m (W), 17 m (R), 8 m (L) | ||
| Image enhancements | WDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror Function, Privacy Mask, ROI | ||
| Motion Detection | Yes | ||
| Smart Features | Advanced Artificial Intelligence: Classification of human, vehicle and non-motorized vehicle about: Area intrusion, Line crossing, entry region, exit region Facial detection and face capture Counting of people, vehicles and non-motorized vehicles Video metadata (Feature Extraction): - Human: up to 13 characteristics (clothing color, hat, backpack, ...) - Vehicle: up to 5 characteristics (color, type, make, model and address) - Non-motorized vehicle: Up to 1 features valign="middle" class="table-data"> | Audio compression | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT | ||
| Internal storage | MicroSD card up to 256GB | ||
| EIS (Electronic Image Stabilizer) | Yes | ||
| Remote Access | Web Browser, Safire Smart Smartphone App, Safire Smart VMS PC Software | ||
| Interoperability | ONVIF | ||
| Power | DC 12 V / 702 mA / 9W max. / PoE IEEE802.3af | ||
| Protection grade | Waterproof IP67 | ||
| Material | Metal | ||
| Temp. operation | -30º C ~ +60º C | ||
| Dimensions | 80.30 (H) x 80.50 (W) x 217.80 (Fo) mm | ||
| Weight | 680 g |
