| Brand | Safire Smart |
| Gamma | B1 Night Color Economical |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920x1080) |
| Minimum illumination | Color: 0.003 Lux @(F1.0, AGC ON) Night Color, color image 24/7h |
| Lighting Range | Dual lighting: IR up to 20m White LED up to 20m Auto / Manual * Auto: When the camera detects the presence of a person, it changes from black and white mode to color mode, activating its white light |
| Day/night | Removable ICR mechanical filter |
| Electronic Shutter | 1/2~1/100,000 s |
| Main Stream Rate | 25 FPS (1080P, 720P) |
| Extra Stream Rate | 25 FPS (720P, D1, CIF) |
| Third Stream Rate | 25 FPS (D1, 480x240, CIF) |
| Compression | H.265 / H.264 |
| Bitrate | 64 Kbps ~ 8 Mbps |
| Optical | Fixed 2.8mm |
| Angle of view (FOV) | H: 95°, V: 55°, D: 109° |
| DORI | 41 m (R), 17 m (W), 8 m (R), 4 m (L) |
| Image Enhancements | DWDR, BLC, HLC, 3D-DNR, AWB, ROI, Mirror |
| SMD (Smart Motion Detection) | Smart Motion Detection: Supports human-based motion detection |
| Smart Functions | Line crossing and area intrusion region based on motion detection human Smart events: object abandoned, object removed, Video exceptions (scene change, video loss, ...) |
| Audio | Built-in microphone, 1 Input |
| Compression audio | G711A / U |
| Network interface | Ethernet 10 / 100M BaseT |
| Internal storage | Not available |
| Remote Access | Web Browser, Safire Smart Smartphone App, Safire Smart VMS PC Software |
| Interoperability | ONVIF |
| Power | DC 12 V / 410 mA / 5W max. / PoE IEEE802.3af |
| Protection degree | Waterproof IP67 |
| Temp. operation | -20º C ~ +55º C |
| Dimensions | 84.8 (H) x 113.8 (Ø) mm |
| Weight | 300 g |
Data sheet
