| Brand | Safire |
| Range | ECO |
| Sensor image | High Performance CMOS |
| Maximum resolution | 5 Mpx (2650x1944) at 20 fps |
| Resolution | TVI: 5 Mpx (20 fps) / 4 Mpx (25~30 fps) / 2 Mpx (25~30 fps) |
| Lens | Motorized 2.7~13.5 mm |
| Angle of view (FOV) | 95º - 26º (H), 72º - 20º (V), 126º - 33º (D) |
| Minimum illumination | 0.01 Lux @ (F1.2, AGC ON) |
| Infrared illumination | 0 Lux / Smart IR Matrix LEDs (range 40 m) |
| Day / Night | Auto / Color / BW (black and white) |
| Video output | 1 x BNC HDTV |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, 2D DNR, AE, AGC, ATW, AWB, BLC, HLC, Smart IR |
| Alarm | No available |
| Audio | Not available |
| Power | DC 12 V / 725 mA, 8.7 W max. PoC.at |
| Protection grade | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal and plastic |
| Dimensions | 255.1 (Fo) x 92 (W) x 84.5 (H) x 85.3 (Ø) mm |
| Base diameter | 70 (Ø) mm / 3 screws |
| Weight | 677 g |
