The DS-2CD2063G2-LI2U(2.8mm)(BLACK) is a high-performance IP bullet camera designed for advanced surveillance applications. With its 6 Megapixel resolution, this camera is ideal for monitoring large areas, providing clear and detailed images even in low-light conditions. The device features a hybrid light system that includes both IR and white light, ensuring visibility up to 40 meters. This makes it suitable for various environments, including commercial and residential settings, where reliable security monitoring is essential.
| Brand | HIKVISION |
| Series | PRO |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Maximum Resolution | 6 Megapixel (3200x1800) |
| Main Stream Rate | 25 fps (3200x1800, 2688x1520, 1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (1280x720, 640x480, 640×360) |
| Third Stream Rate | 10 fps (1920x1080, 1280x720, 640x480, 640×360) * The Third Stream is supported under certain configurations |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 16 Mbps |
| Optics | 2.8 mm |
| Field of View (FOV) | H: 105°, V: 55°, D: 127° |
| DORI | 76 m (D), 30 m (O), 15 m (R), 7 m (I) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum Illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with white light |
| Supplementary Illumination | Hybrid Light: IR range 40 m White light range 40 m |
| Day/Night | Removable ICR Mechanical Filter |
| Image Enhancements | WDR (120 dB), BLC, HLC, 3D-DNR, ROI, Mirror Function, Privacy Masking |
| ANR | Yes |
| Motion Detection | Motion Detection 2.0 with human and vehicle classification applied in motion detection. * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Intelligent Functions | AcuSense Deep Learning-based technology for human and vehicle classification with false alarm reduction applied on: Line Crossing, Area Intrusion * Motion detection and AcuSense cannot be enabled simultaneously on the same device. |
| Internal Storage | MicroSD card slot up to 512 GB |
| Audio | Integrated Dual Array Microphone |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bitrate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Environmental Noise Filtering | Yes |
| Network Interface | Ethernet 10 / 100 BaseT |
| Remote Access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200, and Hik-Central |
| Interoperability | ONVIF (Profiles S, G), ISAPI, SDK |
| Power Supply | DC 12 V / 500 mA / 6 W max. PoE IEEE802.3af |
| Protection Grade | IP67 Waterproof |
| Operating Temperature | -30º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 74.4 mm x 176.3 mm (Fo) |
| Base Dimensions | Ø base 70 mm / Ø between screws 55 mm / 3 screws |
| Weight | 515 g |
| Color | Black |
The DS-2CD2063G2-LI2U(2.8mm)(BLACK) is an excellent choice for both residential and commercial security installations. For instance, a retail store can deploy this camera at entry points to ensure comprehensive surveillance coverage. With its high-resolution imaging and motion detection capabilities, store owners can monitor customer activity and deter potential theft. The camera's remote monitoring feature allows users to access live feeds via a smartphone app, providing peace of mind when away from the premises. Additionally, the IP67 waterproof rating ensures durability in various weather conditions, making it suitable for outdoor use. The integration of AcuSense technology further enhances security by reducing false alarms, allowing for more efficient monitoring. Overall, this camera is a reliable solution for enhancing security in any environment.
