| Brand | HIKVISION |
| Range | Wi-Fi |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Maximum resolution | 2 Megapixel (1920×1080) |
| Main Stream Rate | 25 fps (1920×1080, 1280×720) |
| Extra Stream Rate | 25 fps (640x480, 640×360) |
| Compression | H.265+ / H.264+ / H.265 / H.264 |
| Bitrate | 32 Kbps ~ 8 Mbps |
| Optics | 2.8 mm |
| Angle of view (FOV) | H: 111°, V: 59°, D: 133° |
| DORI | 42 m (D), 17 m (W), 9 m (R), 4 m (L) |
| Electronic Shutter | 1/3~1/100,000 s |
| Minimum illumination | Color: 0.005 Lux @(F1.6, AGC ON) 0 Lux with EXIR IR range 30 m |
| Day/night | Removable ICR mechanical filter |
| Image enhancements | WDR (120 dB), BLC, 3D-DNR, Mirror, Privacy masking |
| Motion detection | Yes |
| Internal storage | MicroSD card slot up to 512 GB |
| Audio | Built-in microphone and speaker |
| Network interface | Ethernet 10 / 100 BaseT Wi-Fi IEEE802.11 b/g/n |
| WiFi Frequency | 2.412 GHz ~ 2.472 GHz |
| WiFi Modulation | 802.11n: BPSK, QPSK, 16QAM, and 64QAM 802.11b: DBPSK and DQPSK, CCK 802.11g: BPSK, QPSK, 16QAM, and 64QAM |
| Remote Access | Wired connection: Web Browser, Smartphone App Hik-Connect, iVMS-4200 PC Software With Wi-Fi connection: Web Browser, iVMS-4200 PC Software * With Wi-Fi connection you cannot connect with Hik-Connect directly |
| Interoperability | ONVIF, ISAPI |
| Power | DC 12 V / 500 mA / 6.5 W max. |
| Protection grade | Waterproof IP66 |
| Material | Base: Metal Front cover: Polycarbonate Back cover: Polycarbonate |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | Ø 126 mm × 96.1 mm (H) |
| Dimensions of the base | Ø base 126 mm / Ø between screws 83.6 mm / 2 screws |
| Weight | 590 g |
