| Brand | Hivision |
| Range | Value |
| Sensor image | 1/2.8“ Progressive Scan CMOS |
| Resolution | 1080p (1920x1080) at 25 FPS |
| Output video | 1x BNC format HDTVI/HDCVI/AHD/CVBS |
| Minimum illumination | 0.005 Lux @ F1.6, AGC ON)(Color) 0.001 Lux @ (F1.6, AGC ON)(B/W) |
| Optics | 4.8~120 mm (25X optical zoom) |
| View angle | 57.6º - 2.5º (H), 314.4º - 1.4º (V), 64.5º - 2.9º (D) |
| Focus | Auto / Semi / Manual |
| Digital zoom | 16X |
| Electronic shutter | 1/1s~1/10,000s |
| Day / Night | Removable ICR mechanical filter |
| Image enhancements | BLC / HLC / WDR (120dB), AWB, ATW, AGC, 3D-NR |
| Image stabilizer | Yes (Electronic image stabilizer) |
| Privacy masks | Up to 8 areas |
| Range Pan/Tilt | Horizontal: 0°~360°, Vertical: 5°~90° auto flip 180° |
| Manual speed | Horizontal: 0.1°~100° /s, Vertical: 0.1°~80° /s |
| Speed between Presets | Horizontal: 100° /s, Vertical: 80° /s |
| Preset positions | 256 preset, 5 auto pattern, 10 auto tour, auto pan, auto scan |
| Communication | RS485, Pelco P / Pelco D / HIKVISION |
| Audio | Not available |
| Alarms | 2 Inputs / 1 Output |
| Power | DC 12 VDC / 1 A, < 12W |
| Temp. operation | -30º C ~ +65º C (<90% humidity) |
| Protection degree | IP66 / Surge 4000V |
| Dimensions (without support) | (indoor) 179 mm (H) x 165 (Ø) mm (in-ceiling) 168 mm (H) x 165 (Ø) mm |
| Weight (without support) | 2 Kg |
Data sheet
