| Brand | Hikvision |
| Range | Value |
| Image sensor | 5 Mpx CMOS |
| Maximum resolution | 5 Mega pixel (2560 x 1944) at 25 fps |
| Resolution | TVI: 5Mpx (20fps), 4Mpx (25~30fps), 1080p (25~30fps) CVI: 4Mpx (25~30fps) AHD: 5Mpx (20fps), 4Mpx (25~30fps) CVBS: PAL/NTSC |
| Lens | Motorized varifocal lens 2.7~13.5 mm |
| Angle of View (FOV) | H: 95~26° (H), 72~20° (V), 126~33° (D) |
| Minimum Illumination | Color: 0.01 Lux @ (F1.2, AGC ON) Black and white: 0 lux with IR |
| Infrared illumination | 0 Lux / (Smart IR LEDs range 40 m) |
| Day / Night | Auto / Color / BW (Black and White) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Using Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | DWDR, 2DNR, BLC, HLC, AGC, AWB, Smart IR |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 8.8 W max. |
| Protection grade | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Front cover: Metal Camera body: Plastic |
| Dimensions | 84.5 mm (H) × 92 mm (W) × 255.1 mm (D) |
| Base dimensions | base Ø 85.3 mm / Ø between screws 70 mm / 3 screws |
| Weight | 682 g |
