| Brand | Hikvision |
| Range | Value |
| Image sensor | 2 Mpx CMOS |
| Maximum resolution | 1080p (1920x1080) at 30 fps |
| Resolution | 1080p (25~30 fps) |
| Lens | 2.8 mm |
| Angle of view (FOV) | 106º (H) |
| Minimum illumination | 0.005 Lux@(F1.2, AGC ON) |
| Infrared illumination | 0 Lux / (Smart EXIR IR range 30 m) |
| Day / Night | Auto / Color / Black and white (ICR) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Via Switch |
| Basic functions | OSD menu (remote) |
| Configurable OSD functions | WDR (120 dB), BLC, HLC, 3DNR, AGC, AWB, Mirror function, Smart IR |
| Communication | HIKVISION-C |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 4.6 W max. |
| Protection degree | Waterproof IP67, vandal-resistant IK10 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 110.8 mm x 84.7 mm (Al) |
| Base diameter | Ø base 110.8 mm / Ø between screws 100.36 mm / 3 screws |
| Weight | 374 g |
