| Brand | Hikvision |
| Range | CORE |
| Image Sensor | High Performance CMOS |
| Maximum resolution | 5Mpx (2560x1944) at 20fps |
| Resolution | TVI: 5Mpx (20fps), 4Mpx (25~30 fps), 1080p (25~30 fps) AHD: 5Mpx (20fps), 4Mpx (25~30 fps) CVI: 4Mpx (25~30 fps) CVBS: PAL/NTSC |
| Lens | 2.4 mm |
| Angle of view (FOV) | 110º (H), 81º (V), 137º (D) |
| Minimum illumination | 0.01 Lux @ (F1.2, AGC ON) |
| Illumination infrared | 0 Lux / (Smart EXIR IR range 30 m) |
| Day / Night | Auto / Color / Black and white (ICR) |
| Output video | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Video output switching | Via Switch |
| Functions basic | OSD menu (remote) |
| Configurable OSD functions | DWDR, BLC, 2DNR, AGC, AWB, Mirror function, Smart IR |
| Communication | HIKVISION-C |
| Lens Positioning | 3 Axis |
| Power | DC 12 V / 4.3 W max |
| Protection grade | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Metal |
| Dimensions | Ø 82.6 mm × 79.37 mm (H) × 90 mm (Fo) |
| Base diameter | Ø base 82.6 mm / Ø between screws 60 mm / 3 screws |
| Weight | 289 g |
