| Brand | Hikvision |
| Gamma | Value |
| Image Sensor | 3K CMOS |
| Maximum resolution | 3K (2960x1665) at 20 fps |
| Resolution | TVI: 3K (20 fps), 4 Mpx (25~30 fps), 1080p (25~30 fps) CVI: 4Mpx (25~30 fps) AHD: 5Mpx (30 fps), 4 Mpx (25~30 fps) CVBS: PAL/NTSC |
| Lens | 3.6 mm |
| Angle of view (FOV) | 83º (H), 48º (V), 102º (D) |
| Minimum illumination | Color: 0.01 Lux @ (F1.2, AGC ON) Black and white: 0 lux with IR |
| Infrared lighting | Dual light: Smart IR Range 40 m White light range 40 m |
| Day / Night | Auto / Color / Black and White (ICR) |
| Video output | 1 x BNC switchable HDTVI / HDCVI / AHD / CVBS |
| Audio | Integrated microphone (Audio via coaxial cable in TVI technology) |
| Video output switching | Via Switch |
| Functions basic | OSD menu (remote) |
| Configurable OSD functions | DWDR, AGC, AWB, Smart IR |
| Positioning Lens | 3 Axis |
| Power | DC 12 V / 4.5 W max |
| Protection degree | Waterproof IP67 |
| Temp. operation | -40º C ~ +60º C |
| Material | Front cover: Metal Body: Plastic |
| Dimensions | 75.4 mm (H) x 78.9 mm (W) × 216.6 mm (D) |
| Base diameter | base Ø 69.97 mm / Ø between screws 55 mm / 3 screws |
| Weight | 340 g |
